Airtac LGC Series Cross Roller Guide Rail LGC1A70R19-H
Category: Linear Guides , Brand: AirTAC , Series: LGC
AirTAC LGC Series Cross Roller Guide LGC1A70R19-H Technical Details
- Model: LGC1A70R19-H
- Type: Precision cross roller linear guide
- Rail width: 70mm (standardized compact profile)
- Roller arrangement: 90° orthogonal cross pattern
- Dynamic load rating (C): 18.5kN
- Static load rating (C0): 29.4kN
- Precision grade: P5 (high-precision grinding)
- Preload class: Medium (3-5μm clearance elimination)
- Seal type: Triple labyrinth seal + wiper
- Material: Carburized steel SCM415 (HRC 58-62)
- Temperature range: -20℃ to 100℃ (dry operation)
- Corrosion protection: Black oxide coating + anti-rust oil
- Weight: 6.8kg/m (linear density)
- Dimensions per 100mm block: 70mm(W) × 64mm(H) × 100mm(L)
- Mounting hole pattern: 60mm longitudinal spacing (M6 threaded)
Ultra-compact cross roller guide with space-saving design, delivering ±5μm/m positioning repeatability through hardened V-groove raceways. Features staggered roller orientation for omnidirectional stiffness, optimized for multi-axis compensation in cleanroom environments. Requires minimal lubrication intervals (2,000km service life with proper maintenance).
- Semiconductor wafer handling robots
- Medical CT scanner gantry movement
- 5-axis CNC rotary-tilting tables
- Laser cutting Z-axis precision stages
- Optical inspection equipment alignment systems
Installation criticals:
Cleanroom assembly recommended (ISO Class 5 or better).
Apply initial lubrication with ISO VG10-15 grease.
Torque mounting bolts to 4.5N·m ±10% in crisscross sequence.
| Property | Property Value |
|---|---|
| sku | LGC1A70R19-H |
| Roller Outer Diameter | 1.5mm |
| Type | Three-column |
