Airtac LGC Series Cross Roller Guide Rail LGC1A80R19-H
Category: Linear Guides , Brand: AirTAC , Series: LGC
AirTAC LGC Crossed Roller Guide LGC1A80R19-H Technical Details
- Model: LGC1A80R19-H
- Type: Crossed roller linear guide with recirculating system
- Rail width: 80mm
- Roller diameter: φ6.35mm
- Preload class: Light preload (C0)
- Dynamic load capacity (C): 58kN
- Static load capacity (C0): 115kN
- Accuracy grade: P5 (High precision)
- Sealing: Triple-lip contact seals + stainless steel scrapers
- Material: Carburized steel with black oxide coating
- Operating temperature: -20℃ to 100℃
- Lubrication: Pre-packed grease (Relubrication interval: 1,000km)
- Weight per meter: 12.8kg/m
- Standard carriage dimensions: 160mm(L) × 80mm(W) × 48mm(H)
- Mounting hole spacing: 140mm longitudinal, 60mm transverse
- Protection rating: IP65 (Dust-tight & protected against water jets)
High-rigidity crossed roller guide featuring alternating orthogonal roller arrangement for multi-directional load capacity. The hardened raceway and optimized roller path geometry enable ±0.5μm/m positioning repeatability. Integrated sealing system combines particle exclusion and lubricant retention, with optional wiper kits for harsh environments.
- Precision CNC grinding machine Z-axis guidance
- Semiconductor wafer handling robots
- Optical measurement equipment stages
- High-speed PCB drilling machines
- Medical linear accelerator positioning systems
Installation guidance:
Requires mounting surface flatness ≤0.01mm/m and parallelism ≤0.02mm between rails.
Use 12.9 grade mounting screws torqued to 45N·m in crisscross pattern.
Thermal expansion compensation required for installations over 1.5m length.
| Property | Property Value |
|---|---|
| sku | LGC1A80R19-H |
| Roller Outer Diameter | 1.5mm |
| Type | Three-column |
