Airtac LGC Series Cross Roller Guide Rail LGC1B20R6-H
Category: Linear Guides , Brand: AirTAC , Series: LGC
AirTAC LGC1B20R6-H Cross Roller Guide Specifications
- Model: LGC1B20R6-H
- Type: Precision cross roller guide with high rigidity
- Rail width: 20mm
- Roller diameter: φ6mm (chrome steel GCr15)
- Preload level: Medium preload (C2 grade)
- Dynamic load capacity: 3,800N
- Static load capacity: 6,200N
- Accuracy grade: P5 (≤5μm/100mm running parallelism)
- Max travel speed: 2m/s
- Operating temperature: -10℃ to 80℃
- Lubrication: Pre-packed grease (replenishment every 1,000km)
- Weight: 1.8kg per 100mm unit length
- Dimensions (per block): 60mm(L) × 20mm(W) × 15mm(H)
- Rail mounting hole spacing: 30mm pitch (M4 threaded holes)
- Surface treatment: Black oxide coating (Fe3O4)
High-precision linear motion system combining radial and axial rollers in orthogonal arrangement, delivering exceptional moment resistance and positional stability. Features hardened raceways (HRC58-62) and optimized roller contact angles for minimized friction fluctuation. Compatible with automatic lubrication systems through integrated grease nipples.
- CNC rotary table indexing mechanisms
- Semiconductor wafer handling robots
- Optical lens grinding equipment
- Coordinate measuring machine (CMM) Z-axis
- High-speed PCB drilling machines
Installation guidelines:
Requires mounting surface flatness ≤0.01mm/m. Use torque-controlled wrench
(1.2-1.5N·m for M4 screws) in diagonal tightening sequence. Avoid thermal expansion
by maintaining 20-25℃ ambient during installation.
| Property | Property Value |
|---|---|
| sku | LGC1B20R6-H |
| Roller Outer Diameter | 1.5mm |
| Type | Four-Row Type |
