Airtac LGC Series Cross Roller Guide Rail LGC1B20R7-H
Category: Linear Guides , Brand: AirTAC , Series: LGC
AirTAC LGC Cross Roller Guide LGC1B20R7-H Technical Specifications
- Model: LGC1B20R7-H
- Type: Precision cross roller linear guide
- Rail width: 20mm
- Number of blocks: 1 (single carriage)
- Roller arrangement: 90° orthogonal cross layout
- Preload class: Medium preload (R7 grade)
- Dynamic load rating (C): 5,800N
- Static load rating (C0): 9,200N
- Stiffness: 280N/μm (radial direction)
- Accuracy grade: Normal class (≤15μm/4m)
- Sealing: Double-sided wiper seals + grease retainers
- Lubrication: Pre-lubricated with VG2 grease
- Material: Carburized steel (HRC58-62)
- Mounting hole spacing: 60mm standard pitch
- Weight: 2.5kg/m (rail) + 0.8kg (block)
- Dimensions (L×W×H):
- Standard rail length: 1000mm (customizable)
- Block size: 60mm(L) × 34mm(W) × 27mm(H)
- Rail height: 20mm
- Operating temperature: -10℃ to 80℃
- Vibration resistance: 49m/s² max
High-rigidity cross roller guide with optimized stress distribution, featuring alternating orthogonal rollers for multi-directional load capacity. The chrome-plated raceway surface ensures corrosion resistance and smooth motion characteristics. Designed for applications requiring minimal elastic deformation under heavy moment loads.
- CNC rotary table bearing replacement
- Precision optical stage positioning
- Semiconductor wafer handling robots
- Medical CT scanner gantry systems
- 5-axis machining center swivel heads
Installation note:
Use torque wrench (2.5-3.0N·m) for mounting bolts. Maintain perpendicularity within 0.02mm/100mm during rail alignment. Apply EP2 grease every 500km travel distance.
- Maximum allowable moment: 820N·m (MR), 410N·m (MP)
- Surface roughness requirement: Ra0.8 or better on mounting surfaces
- Storage humidity: Below 70% RH (anti-corrosion coating recommended)
| Property | Property Value |
|---|---|
| sku | LGC1B20R7-H |
| Roller Outer Diameter | 1.5mm |
| Type | Four-Row Type |
