Airtac LGC Series Cross Roller Guide Rail LGC1B30R10-H
Category: Linear Guides , Brand: AirTAC , Series: LGC
AirTAC LGC Cross Roller Guide LGC1B30R10-H Technical Specifications
- Model: LGC1B30R10-H
- Series: LGC1B heavy-duty precision series
- Rail width: 30mm
- Roller diameter: 10mm (chrome steel GCr15)
- Preload class: Medium (C2 grade)
- Basic dynamic load rating: 15.2kN
- Basic static load rating: 24.5kN
- Max travel speed: 5m/s
- Repeat positioning accuracy: ±0.005mm
- Sealing type: Triple labyrinth seal with grease retention
- Surface treatment: Black oxide coating (Fe3O4)
- Operating temperature: -10℃ to 80℃
- Weight per 1000mm unit: 3.8kg (rail only)
- Dimensions (W×H×L): 30mm × 24.5mm × customizable length (standard 500-2000mm)
- Mounting hole pattern: M6×12mm pitch (counterbored holes)
- Rigidity: 580N/μm (vertical direction)
Precision-ground cross roller guide featuring staggered 90° V-groove design for simultaneous load bearing in all directions. The hardened raceway (HRC58-62) ensures exceptional wear resistance, while the optimized roller circulation system minimizes vibration during high-speed reciprocation. Requires periodic lubrication with ISO VG32-grade guideway oil.
- CNC coordinate measuring machines (CMM)
- Semiconductor wafer handling robots
- Precision optical lens grinding equipment
- High-speed PCB drilling/spindle units
- Medical CT scanner gantry systems
Installation protocol:
Maintain ≤0.02mm/m straightness tolerance during rail alignment.
Use 4-6Nm torque for M6 mounting screws with Loctite 243 threadlocker.
Avoid direct particulate contamination during assembly.
| Property | Property Value |
|---|---|
| sku | LGC1B30R10-H |
| Roller Outer Diameter | 1.5mm |
| Type | Four-Row Type |
