Airtac LGC Series Cross Roller Guide Rail LGC1B30R11-H
Category: Linear Guides , Brand: AirTAC , Series: LGC
AirTAC LGC1B30R11-H Crossed Roller Guide Specifications
- Model: LGC1B30R11-H
- Type: Precision crossed roller linear guide
- Rail width: 30mm
- Roller diameter: 3mm
- Standard carriage length: 100mm (customizable)
- Dynamic load rating: 12.5kN
- Static load rating: 24.5kN
- Precision grade: Normal (C) / High (H) optional
- Material: High-carbon chromium bearing steel (SUJ2 equivalent)
- Surface hardness: 58-64 HRC
- Sealing: Triple-lip rubber seals + stainless steel scrapers
- Operating temperature: -20℃ to 100℃
- Lubrication: Pre-lubricated with lithium complex grease
- Protection rating: IP54 (standard), IP67 optional
- Weight per meter: 3.8kg/m ±2%
- Carriage dimensions: 100mm(L) × 34mm(W) × 24mm(H)
- Rail dimensions (per 1m): 1000mm(L) × 30mm(W) × 18mm(H)
High-rigidity crossed roller guide featuring 90° V-groove design for simultaneous load bearing in all directions. The alternating orthogonal roller arrangement eliminates clearance while maintaining smooth motion, achieving positioning repeatability of ±5μm. Includes hardened raceways and corrosion-resistant stainless steel end caps.
- High-precision CNC rotary tables
- Semiconductor wafer handling robots
- Medical CT scanner gantries
- Optical alignment stages
- Automated coordinate measuring machines
- Lithography equipment components
Installation note:
Requires mounting surface flatness ≤0.01mm/m and parallelism ≤0.02mm between rails.
Use M4×8mm counterbore screws (ISO 4762) at 80-100mm intervals with 0.5-0.7Nm torque.
Relubricate every 1,000km travel or 6 months.
| Property | Property Value |
|---|---|
| sku | LGC1B30R11-H |
| Roller Outer Diameter | 1.5mm |
| Type | Four-Row Type |
