Airtac LGC Series Cross Roller Guide Rail LGC1B30R8-H
Category: Linear Guides , Brand: AirTAC , Series: LGC
AirTAC LGC1B30R8-H Crossed Roller Guide Specifications
- Model: LGC1B30R8-H
- Rail width: 30mm
- Roller arrangement: 90° crossed cylindrical rollers (X-axis configuration)
- Preload level: Medium preload (C2 grade)
- Accuracy class: P5 (High precision)
- Dynamic load capacity: 12.5kN
- Static load capacity: 24.8kN
- Stiffness: 420 N/μm
- Repeat positioning accuracy: ±2μm
- Max travel speed: 5m/s
- Material: Bearing steel (SUJ2 equivalent) with multilayer electroless nickel plating
- Operating temperature: -10℃ to 80℃
- Lubrication: Pre-lubricated with lithium complex grease (regreasing possible via 4 lubrication ports)
- Weight: 3.8kg per 1000mm length
- Dimensions (W×H): 30mm × 30mm (rail profile)
- Mounting hole pattern: M6 threaded holes @ 60mm pitch
Precision crossed roller guide engineered for ultra-stable linear motion in multi-axis systems. Features zero-backlash operation through controlled preload and hardened raceways with mirror finishing (Ra 0.2μm). The compact symmetrical design enables equal load distribution in all directions, making it ideal for rotary-to-linear motion conversion applications.
- Semiconductor wafer handling robots
- 5-axis CNC rotary tables
- Coordinate measuring machine (CMM) arms
- Photonics alignment stages
- High-speed pick-and-place units
- Medical CT scanner gantries
Installation note:
Requires mounting surface flatness ≤0.01mm/m. Use torque wrench (recommended 5.4N·m for M6 bolts)
with sequential tightening pattern. Perform laser alignment after thermal stabilization.
| Property | Property Value |
|---|---|
| sku | LGC1B30R8-H |
| Roller Outer Diameter | 1.5mm |
| Type | Four-Row Type |
