Airtac LGC Series Cross Roller Guide Rail LGC1B30R9-H
Category: Linear Guides , Brand: AirTAC , Series: LGC
AirTAC LGC Cross Roller Guide LGC1B30R9-H Technical Specifications
- Model: LGC1B30R9-H
- Type: Precision cross roller linear guide
- Rail width: 30mm
- Roller diameter: φ3.5mm (chrome steel)
- Standard carriage length: 90mm
- Basic dynamic load rating: 12.5kN
- Basic static load rating: 24.6kN
- Preload level: Medium (P2 class)
- Accuracy grade: High precision (C class ±5μm/300mm)
- Repeat positioning accuracy: ≤0.002mm
- Material: Carburized steel SCM415 (HRC58-62)
- Sealing: Triple labyrinth seal with grease retention
- Operating temperature: -15℃ to 80℃
- Protection rating: IP54 (standard), IP67 optional
- Weight: 2.8kg per meter (rail only), 1.2kg (carriage assembly)
- Dimensions:
- Rail: 30(W)×27(H)mm
- Carriage: 90(L)×58(W)×34(H)mm
- Mounting hole spacing: 60mm longitudinal, 40mm transverse
High-rigidity cross roller guide featuring alternating orthogonal roller arrangement for multi-directional load capacity. The LGC1B30R9-H combines X-axis and Z-axis rigidity in compact dimensions, with optimized preload adjustment through selective assembly of roller diameters. Includes hardened raceways and anti-creep design for high moment resistance (Mx=82Nm, My=110Nm, Mz=150Nm).
- High-speed CNC grinding machine Z-axis
- Semiconductor wafer handling robots
- Precision optical inspection equipment
- Medical CT scanner gantry systems
- 5-axis additive manufacturing platforms
Installation guidance:
Maintain flatness ≤0.01mm/m on mounting surface. Use torque wrench (2.5-3.0Nm for M5 screws)
with sequential tightening pattern. Requires initial lubrication with ISO VG32 guideway grease.
| Property | Property Value |
|---|---|
| sku | LGC1B30R9-H |
| Roller Outer Diameter | 1.5mm |
| Type | Four-Row Type |
