Airtac LGC Series Cross Roller Guide Rail LGC1B40R11-H
Category: Linear Guides , Brand: AirTAC , Series: LGC
AirTAC LGC Crossed Roller Guide LGC1B40R11-H Technical Details
- Model Code: LGC1B40R11-H
- Series: LGC (High Rigidity Crossed Roller Series)
- Rail Width: 40mm (Standard Size)
- Roller Arrangement: 45° Crossed Roller Pattern
- Preload Class: Medium Preload (C3 Grade)
- Dynamic Load Capacity: 12.5kN (X/Y axis)
- Static Load Capacity: 24.6kN
- Positioning Accuracy: ±5μm/300mm
- Max Travel Speed: 5m/s
- Seal Type: Triple-Layer Stainless Steel Scraper + Rubber Wiper
- Lubrication: Pre-lubed with AAF-13A Grease (Relubrication Ports Provided)
- Material: S55C Carbon Steel (Hardened to HRC58-62)
- Surface Treatment: Black Oxide Coating (5-8μm)
- Operating Temp: -20℃ to 100℃ (Dry)/ -10℃ to 80℃ (Lubricated)
- Weight per Unit Length: 3.8kg/m (Rail Only)
- Standard Rail Length: 1000mm (Customizable in 50mm increments)
- Slider Dimensions: 115mm(L) × 40mm(W) × 30mm(H)
- Mounting Hole Pattern: M6×1.0 Thread @ 60mm Pitch
Precision-ground crossed roller guide offering near-zero backlash operation, designed for multi-axis systems requiring micron-level positioning stability. Features hardened raceways with 72 high-precision cylindrical rollers (Ø4×6mm) arranged in orthogonal directions, providing equal load capacity in all radial directions. Includes integrated debris management system with magnetic seals.
- 5-axis CNC rotary tables and indexers
- Semiconductor wafer handling robots
- Optical measurement CMM arms
- High-speed PCB drilling machines
- Medical CT scanner gantries
- Precision rotary stages for laser processing
Mounting Protocol:
Requires granite surface plate alignment during installation (flatness ≤0.01mm/m²).
Torque mounting bolts to 5.4N·m in crisscross pattern. Thermal expansion compensation
required for installations exceeding 800mm length.
| Property | Property Value |
|---|---|
| sku | LGC1B40R11-H |
| Roller Outer Diameter | 1.5mm |
| Type | Four-Row Type |
