Airtac LGC Series Cross Roller Guide Rail LGC1B40R13-H
Category: Linear Guides , Brand: AirTAC , Series: LGC
AirTAC LGC1B40R13-H Crossed Roller Guide Specifications
- Model: LGC1B40R13-H
- Type: Precision crossed roller linear guide
- Rail width: 40mm
- Roller diameter: Φ6.35mm (1/4")
- Preload class: Medium preload (C2)
- Dynamic load capacity: 18.5kN
- Static load capacity: 30.2kN
- Standard carriage length: 130mm
- Repeat positioning accuracy: ±0.002mm
- Operating temperature: -10℃ to 80℃
- Seal type: Triple labyrinth seal with grease retention
- Mounting hole pattern: 60mm × 60mm (4×M6 threaded holes)
- Material: Alloy steel (SCM435) with hardened raceway (HRC58-62)
- Surface treatment: Black oxide coating
- Weight per unit: 5.2kg (per 1000mm rail length)
- Dimensions (W×H×L): 40mm × 20mm × Custom length (standard 500-4000mm)
- Protection rating: IP54 (dust protected & water splashed)
High-rigidity crossed roller guide featuring 90° V-groove design for simultaneous absorption of radial and axial loads. The staggered roller arrangement eliminates clearance while maintaining smooth motion, with 2.5x higher stiffness than conventional ball guides. Includes pre-loaded rollers for vibration-free operation in multi-axis systems.
- High-precision CNC rotary tables
- Semiconductor wafer handling robots
- Optical measurement equipment stages
- Medical CT scanner gantries
- 5-axis machining center trunnions
Installation note:
Requires surface flatness ≤0.01mm/m and parallelism ≤0.02mm between rails.
Use torque wrench (12-14N·m) for mounting bolts in cross pattern sequence.
Apply ISO VG68 slideway grease during initial commissioning.
| Property | Property Value |
|---|---|
| sku | LGC1B40R13-H |
| Roller Outer Diameter | 1.5mm |
| Type | Four-Row Type |
