Airtac LGC Series Cross Roller Guide Rail LGC1B50R13-H
Category: Linear Guides , Brand: AirTAC , Series: LGC
AirTAC LGC Cross Roller Guide LGC1B50R13-H Technical Specifications
- Model: LGC1B50R13-H
- Type: Precision cross roller linear guide
- Rail width: 50mm (nominal size)
- Roller diameter: 13mm (high-precision G5 grade)
- Dynamic load rating (C): 12.5kN
- Static load rating (C0): 24.8kN
- Preload level: Medium (3-5μm)
- Repositioning accuracy: ±2μm
- Max travel speed: 2m/s
- Operating temperature: -20℃ to 100℃
- Material: Carburized & hardened steel (HRC58-62)
- Sealing: Triple labyrinth seal with grease retention
- Lubrication: Pre-lubricated with lithium complex grease
- Mounting hole spacing: 80mm (standard pattern)
- Weight per meter: 12.8kg/m ±2%
- Dimensions (W×H×L): 50mm × 30mm × Custom length (standard 1000-4000mm)
High-rigidity cross roller guide featuring 90° V-type raceway design for simultaneous load bearing in all directions. The staggered roller arrangement eliminates clearance while maintaining smooth motion, with hardened raceways providing exceptional wear resistance. Includes integrated oil holes for maintenance lubrication.
- Semiconductor wafer handling robots
- Medical CT scanner gantry systems
- Precision optical alignment stages
- High-speed CNC grinding machine slides
- Lithography equipment positioning systems
Installation note:
Requires mounting surface flatness ≤0.01mm/m and parallelism ≤0.02mm between rails.
Use torque wrench (12-15N·m) for block fastening bolts in crisscross sequence.
- Dust resistance: Meets JIS B 0152 Class 5
- Corrosion protection: 96hr salt spray test passed
- Vibration resistance: 5-2000Hz, 30m/s² max
| Property | Property Value |
|---|---|
| sku | LGC1B50R13-H |
| Roller Outer Diameter | 1.5mm |
| Type | Four-Row Type |
