Airtac LGC Series Cross Roller Guide Rail LGC1B50R16-H
Category: Linear Guides , Brand: AirTAC , Series: LGC
AirTAC LGC1B50R16-H Crossed Roller Guide Specifications
- Model: LGC1B50R16-H
- Type: High-precision crossed roller linear guide
- Rail width: 50mm
- Roller diameter: 16mm (precision grade P5)
- Preload level: Medium (C2 class)
- Dynamic load rating (C): 23.5kN
- Static load rating (C0): 38.7kN
- Stiffness: 420 N/μm
- Accuracy grade: Normal (N) / High (H) optional
- Material: SUJ2 bearing steel (HRC 58-62)
- Sealing: Triple labyrinth seal + grease retention design
- Temperature range: -20℃ to 100℃
- Weight: 8.2kg/m (rail only), 3.1kg per block
- Dimensions (single rail): 50mm(W) × 35mm(H) × customizable length
- Mounting hole spacing: 60mm pitch (M8 threaded holes)
- Lubrication: Grease nipple (Alvania No.2 recommended)
Industrial-grade crossed roller guide featuring X-axis/Y-axis integrated structure with 90° V-groove design. Provides ±0.5μm/m positioning repeatability through optimized roller path geometry. The staggered roller arrangement eliminates clearance while maintaining smooth motion. Includes hardened raceways with mirror finishing (Ra 0.1μm).
- Semiconductor wafer handling robots
- 5-axis CNC rotary tables
- Coordinate measuring machines (CMM)
- High-speed laser cutting Z-axis mechanisms
- Precision optical alignment stages
Installation note:
Requires granite surface plate alignment during mounting (flatness ≤3μm).
Use 4.8Nm torque for M8 mounting screws with Loctite 243.
Run-in with ISO VG32 oil for initial 50km operation.
- Servo motors: Panasonic MINAS A6 series
- Linear scales: Heidenhain LIDA 485
- Mounting base: Granite or stress-relieved cast iron
| Property | Property Value |
|---|---|
| sku | LGC1B50R16-H |
| Roller Outer Diameter | 1.5mm |
| Type | Four-Row Type |
