Airtac LGC Series Cross Roller Guide Rail LGC1B50R19-H
Category: Linear Guides , Brand: AirTAC , Series: LGC
AirTAC LGC Crossed Roller Guide LGC1B50R19-H Technical Specifications
- Model: LGC1B50R19-H
- Type: Precision crossed roller linear guide
- Rail width: 50mm
- Roller arrangement: 90° orthogonal cross layout
- Dynamic load capacity (C): 15,800N
- Static load capacity (C0): 26,500N
- Preload level: Medium (R19 class)
- Accuracy grade: P5 (High precision)
- Repeat positioning accuracy: ±0.002mm
- Roller diameter: 4.762mm (3/16")
- Material: Bearing steel (SUJ2 equivalent) with black oxide coating
- Sealing: Triple labyrinth seal with grease retention
- Operating temperature: -20℃ to 100℃
- Lubrication: Pre-lubricated with Kluber Staburags NBU 12/300P
- Weight per unit length: 3.8kg/m (rail only)
- Standard carriage dimensions: 95mm(W) × 50mm(H) × 80mm(L)
- Mounting hole pattern: M6×1.0 thread @ 30mm pitch
Professional-grade crossed roller guide featuring V-V raceway configuration for equal load distribution in all directions. The LGC1B50R19-H combines high moment stiffness (35kN·m/rad) with ultra-smooth motion (friction coefficient <0.003), making it ideal for multi-axis systems requiring micron-level positioning stability. Integrated debris-resistant seals maintain lubrication integrity in ISO Class 5 cleanroom environments.
- Semiconductor wafer handling robots
- 5-axis CNC grinding machine rotary tables
- Photonics alignment stages
- Coordinate measuring machine (CMM) Z-axis columns
- Lithography equipment precision slides
Installation guidance:
Requires granite surface plate calibration during mounting (flatness ≤0.01mm/m²).
Torque mounting bolts to 4.5N·m ±10% using cross-pattern sequence.
Avoid angular misalignment exceeding 0.05° during assembly.
| Property | Property Value |
|---|---|
| sku | LGC1B50R19-H |
| Roller Outer Diameter | 1.5mm |
| Type | Four-Row Type |
