Airtac LGC Series Cross Roller Guide Rail LGC1B60R16-H
Category: Linear Guides , Brand: AirTAC , Series: LGC
AirTAC LGC Crossed Roller Guide LGC1B60R16-H Technical Specifications
- Model: LGC1B60R16-H
- Type: Crossed roller linear guide with integrated rail
- Rail width: 60mm (standard industrial size)
- Roller diameter: 16mm precision-ground chrome steel
- Dynamic load rating: 24.5kN (C)
- Static load rating: 39.2kN (C0)
- Preload class: Medium (P2)
- Sealing system: Triple-lip contact seals + stainless steel wipers
- Material: Carburized steel rail (HRC58-62) / Aluminum alloy carriage
- Accuracy grade: Normal grade (≤50μm/1000mm running parallelism)
- Mounting hole pattern: 60mm × 60mm grid (M8 threaded holes)
- Operating temperature: -20℃ to 80℃ (dry conditions)
- Surface treatment: Black oxide coating (rail) / Anodized finish (carriage)
- Weight: 3.8kg per 100mm carriage length
- Dimensions (carriage): 160mm(L) × 60mm(W) × 60mm(H)
- Standard rail lengths: 500-3000mm (customizable)
Industrial-grade crossed roller guide offering zero-backlash operation and moment load resistance through its unique 90° roller arrangement. The LGC1B60R16-H features hardened V-groove tracks that provide 4-directional load capacity, with permanent lubrication ports for extended maintenance intervals. Its compact profile enables space-efficient integration in high-stiffness applications.
- CNC rotary tables and indexers
- Semiconductor wafer handling robots
- Precision optical alignment stages
- High-speed automated inspection systems
- Medical CT scanner gantries
Installation protocol:
Requires mounting surface flatness ≤0.02mm/m. Use calibrated torque wrench (14-16N·m for M8 bolts)
in crisscross tightening sequence. Apply lithium complex grease (ISO VG 100-150) through
Zerk fittings every 500 operating hours.
| Property | Property Value |
|---|---|
| sku | LGC1B60R16-H |
| Roller Outer Diameter | 1.5mm |
| Type | Four-Row Type |
