Airtac LGC Series Cross Roller Guide Rail LGC1B60R19-H
Category: Linear Guides , Brand: AirTAC , Series: LGC
AirTAC LGC Crossed Roller Guide LGC1B60R19-H Technical Specifications
- Model: LGC1B60R19-H
- Type: Precision crossed roller guideway
- Rail width: 60mm
- Roller diameter: φ6.35mm (precision ground)
- Preload level: Medium (C3 class)
- Dynamic load capacity: 32.5kN
- Static load capacity: 68kN
- Rated stroke: Standard 1000mm (customizable up to 4000mm)
- Accuracy grade: P5 (≤5μm/300mm)
- Material: SCr420H alloy steel (case hardened HRC58-62)
- Sealing: Triple-lip contact seals + stainless steel scrapers
- Lubrication: Pre-lubricated with ARDROX 3952 grease
- Operating temperature: -20℃ to 100℃
- Surface treatment: Black oxide coating (Fe3O4)
- Weight: 3.8kg per 100mm length
- Dimensions (W×H): 60mm × 19mm (rail height)
High-rigidity crossed roller guide featuring V-V raceway configuration for moment load resistance. The 60° contact angle design optimizes load distribution, achieving 30% higher stiffness than conventional linear guides. Includes alignment marks for simplified installation and wear indicators for maintenance scheduling.
- CNC coordinate measuring machines (CMM)
- Semiconductor wafer handling robots
- High-speed PCB drilling equipment
- Precision optical lens grinding systems
- Medical CT scanner gantry movement
Mounting requirements:
Requires surface flatness ≤0.01mm/m and roughness Ra0.8. Use M6×12 mounting screws
(T30 Torx recommended) at 150mm intervals. Relubricate every 500km travel or 6 months.
| Property | Property Value |
|---|---|
| sku | LGC1B60R19-H |
| Roller Outer Diameter | 1.5mm |
| Type | Four-Row Type |
Returns will be accepted for up to 15 days of Customer’s receipt or tracking number on Not used items. You, as a Customer, are obliged to inform us via email before you return the item, only in the case of:
- Received the wrong item.
- Item arrived not as expected (ie. damaged packaging).
- Item had defects.
- Over delivery time.
- The shipper does not allow the goods to be inspected before payment.
The returned product(s) must be in the original packaging, safety wrapped, undamaged and unworn. This means that the item(s) must be safely packed in a carton box for protection during transport, possibly the same carton used to ship to you as a customer.
