Airtac LGC Series Cross Roller Guide Rail LGC1B80R19-H
Category: Linear Guides , Brand: AirTAC , Series: LGC
AirTAC LGC Crossed Roller Guide LGC1B80R19-H Technical Specifications
- Model: LGC1B80R19-H
- Type: Precision crossed roller linear guide
- Dynamic load capacity: 32.5 kN
- Static load capacity: 52.4 kN
- Accuracy grade: P5 (High precision)
- Preload level: Medium (C2 class)
- Rail width: 80 mm
- Carriage length: 190 mm
- Roller arrangement: 90° orthogonal cross layout
- Sealing system: Triple labyrinth seal with grease retention
- Material: GCr15 bearing steel (HRC 60-64 hardness)
- Operating temperature: -15℃ to 100℃
- Protection rating: IP67 (standard), IP69K optional
- Lubrication: Pre-lubed with VG68 grease, 6 relubrication ports
- Repeat positioning accuracy: ±3μm/300mm
- Max travel speed: 5 m/s
- Mounting hole pattern: 25mm x 25mm grid (M8 threaded)
- Weight: 12.8 kg/m (rail), 4.3 kg (carriage)
- Dimensions: Rail: 80mm(W) × 52mm(H) × customizable length (standard 1000/1500/2000mm) Carriage: 190mm(L) × 100mm(W) × 58mm(H)
Industrial-grade crossed roller guide featuring X-axis/Y-axis combined load capacity through orthogonal roller arrangement. The hardened steel construction with chromium plating (5-7μm thickness) ensures wear resistance in contaminated environments. Optimized for multi-directional moment load applications requiring micron-level stability.
- CNC rotary tables & indexers
- Semiconductor wafer handling robots
- Optical measurement equipment stages
- High-precision grinding machine Z-axis
- Laser cutting head positioning systems
Installation protocol:
Requires surface flatness ≤0.01mm/m and parallelism ≤0.02mm between rails.
Use 12.9-grade mounting bolts torqued to 29.4 N·m ±10%.
Perform thermal stabilization (3-5 full travel cycles) before precision alignment.
| Property | Property Value |
|---|---|
| sku | LGC1B80R19-H |
| Roller Outer Diameter | 1.5mm |
| Type | Four-Row Type |
