Airtac LRM Miniature Linear Guide LRM12L1X100S12.5AH
2. Anti-drop ball bearing retention mechanism for simplified installation and replacement
3. Japanese-manufactured steel balls ensuring superior sphericity and wear resistance (ISO3290 G10 compliant)
4. Enhanced oil-scraping wipers and upgraded dust-proof sealing system
5. Streamlined profile with concealed fasteners protecting sealing strips and eliminating large particulate contamination
Category: Linear Guides | Brand: AirTAC | Series: LRM
AirTAC LRM Micro Linear Guide Rail LRM12L1X100S12.5AH Specifications
- Model: LRM12L1X100S12.5AH
- Type: Miniature linear motion guide system
- Rail width: 12mm
- Effective stroke: 100mm
- Lead screw pitch: 12.5mm (ball screw option)
- Dynamic load capacity: 850N (C)
- Static load capacity: 1,700N (C0)
- Precision grade: Normal (C) / High (H) available
- Repeat positioning accuracy: ±0.01mm
- Max speed: 1.5m/s
- Operating temperature: -20℃ to 100℃
- Weight: 480g ±2% (complete assembly)
- Dimensions: 182mm(L) × 24mm(W) × 19.5mm(H)
- Seal type: Double-sided wiper with grease retention
- Material: Aluminum alloy rail with hardened steel balls
- Mounting hole spacing: 30mm standard intervals
Ultra-compact linear guide system combining low-friction movement with high rigidity. Features pre-loaded ball bearings and corrosion-resistant anodized surfaces. The integrated ball screw version (AH suffix) provides direct drive capability. Includes mounting holes compatible with M3 fasteners.
- Precision laboratory automation stages
- 3D printer Z-axis positioning systems
- Medical device linear actuators
- Semiconductor wafer handling robots
- Optical lens adjustment mechanisms
Installation note:
Apply Loctite 243 to mounting screws and torque to 0.8-1.2Nm.
Lubricate with ISO VG10-15 grease annually under normal use.
Avoid side-loading beyond 30% of rated capacity.
| Property | Property Value |
|---|---|
| sku | LRM12L1X100S12.5AH |
| Slide Rail Width | 12mm |
