Airtac LRM Miniature Linear Guide LRM12L1X110S17.5AH
$48.82
Regular price
$56.32
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
LRM12L1X110S17.5AH
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
LRM Miniature Linear Guide
1. Stainless steel construction with high rigidity, enabling shared guide rails across same-type carriages
2. Anti-drop ball bearing retention mechanism for simplified installation and replacement
3. Japanese-manufactured steel balls ensuring superior sphericity and wear resistance (ISO3290 G10 compliant)
4. Enhanced oil-scraping wipers and upgraded dust-proof sealing system
5. Streamlined profile with concealed fasteners protecting sealing strips and eliminating large particulate contamination
Category: Linear Guides | Brand: AirTAC | Series: LRM
Installation tip:
Use 4.5Nm torque for M3 mounting screws. Maintain rail parallelism within 0.05mm/m
during assembly. Apply lithium-based grease (ISO VG15-32) during initial commissioning.
2. Anti-drop ball bearing retention mechanism for simplified installation and replacement
3. Japanese-manufactured steel balls ensuring superior sphericity and wear resistance (ISO3290 G10 compliant)
4. Enhanced oil-scraping wipers and upgraded dust-proof sealing system
5. Streamlined profile with concealed fasteners protecting sealing strips and eliminating large particulate contamination
Category: Linear Guides | Brand: AirTAC | Series: LRM
AirTAC LRM12L1X110S17.5AH Miniature Linear Slide Guide Specifications
- Model: LRM12L1X110S17.5AH
- Type: Compact recirculating ball linear guide system
- Rail width: 12mm
- Effective stroke: 110mm
- Dynamic load capacity (C): 1,250N
- Static load capacity (C0): 2,450N
- Preload level: Medium (Z0)
- Accuracy grade: Normal (N)
- Material: Carbon steel rail with aluminum alloy block
- Sealing: Triple labyrinth seal + stainless steel wipers
- Mounting hole spacing: 17.5mm (longitudinal)
- Operating temperature: -20℃ to 80℃
- Protection rating: IP54
- Weight: 0.68kg ±2%
- Dimensions: 110mm(L) × 24mm(W) × 15.5mm(H)
Ultra-slim linear motion solution combining high rigidity with minimal installation space. Features optimized ball circulation path for smooth operation at speeds up to 5m/s. Includes mounting reference edges for precision alignment. Compatible with automatic lubrication systems.
Ideal for:
- Desktop CNC machine Z-axis mechanisms
- Semiconductor wafer inspection stages
- Pharmaceutical blister packaging systems
- High-speed PCB component placement robots
- Optical lens coating equipment
Installation tip:
Use 4.5Nm torque for M3 mounting screws. Maintain rail parallelism within 0.05mm/m
during assembly. Apply lithium-based grease (ISO VG15-32) during initial commissioning.
| Property | Property Value |
|---|---|
| sku | LRM12L1X110S17.5AH |
| Slide Rail Width | 12mm |
