Airtac LRM Miniature Linear Guide LRM12L1X110S5AH
2. Anti-drop ball bearing retention mechanism for simplified installation and replacement
3. Japanese-manufactured steel balls ensuring superior sphericity and wear resistance (ISO3290 G10 compliant)
4. Enhanced oil-scraping wipers and upgraded dust-proof sealing system
5. Streamlined profile with concealed fasteners protecting sealing strips and eliminating large particulate contamination
Category: Linear Guides | Brand: AirTAC | Series: LRM
AirTAC LRM12L1X110S5AH Miniature Linear Guide Specifications
- Model: LRM12L1X110S5AH
- Rail width: 12mm
- Carriage type: Single flange (L1 series)
- Effective stroke: 110mm
- Dynamic load capacity (C): 1,050N
- Static load capacity (C0): 1,680N
- Precision grade: Normal (N) class (±0.05mm/300mm)
- Ball diameter: 2.381mm
- Material: Carbon steel with chrome plating (rail), aluminum alloy (carriage)
- Sealing: Triple labyrinth seal + stainless steel scrapers
- Mounting hole spacing: 20mm (longitudinal), 10mm (transverse)
- Operating temperature: -20℃ to 80℃
- Weight: 0.25kg (complete unit)
- Dimensions:
- Rail length: 110mm
- Carriage length: 28mm
- Overall height: 15mm
- Width: 12mm
- Lubrication: Pre-lubricated with lithium soap grease
- Protection rating: IP54 (standard seals)
Ultra-compact linear motion solution combining high rigidity with minimal space requirements. Features corrosion-resistant hardened rails (HRC58±2) and optimized ball circuit design for smooth operation. Includes mounting reference edges for precision alignment. Compatible with automated lubrication systems.
- Desktop CNC milling machine X/Y axes
- Pharmaceutical tablet counting mechanisms
- Lens positioning in optical inspection equipment
- PCB drilling/punching machines
- Laboratory sample handling robots
Installation tip:
Apply 4-6Nm torque during rail mounting. Use M3×6 countersunk screws
(max protrusion 2mm below rail) to prevent ball recirculation interference.
| Property | Property Value |
|---|---|
| sku | LRM12L1X110S5AH |
| Slide Rail Width | 12mm |
