Airtac LRM Miniature Linear Guide LRM12L1X120S10BH
2. Anti-drop ball bearing retention mechanism for simplified installation and replacement
3. Japanese-manufactured steel balls ensuring superior sphericity and wear resistance (ISO3290 G10 compliant)
4. Enhanced oil-scraping wipers and upgraded dust-proof sealing system
5. Streamlined profile with concealed fasteners protecting sealing strips and eliminating large particulate contamination
Category: Linear Guides | Brand: AirTAC | Series: LRM
AirTAC LRM12L1X120S10BH Miniature Linear Guide Specifications
- Model: LRM12L1X120S10BH
- Series: LRM (Micro Rail Series)
- Rail Width: 12mm
- Carriage Quantity: Single block (L1)
- Effective Stroke: 120mm (±0.5mm tolerance)
- Dynamic Load Capacity (C): 1,470N
- Static Load Capacity (C0): 2,940N
- Precision Grade: Normal grade (N) with ±50μm/300mm accuracy
- Repeat Positioning Accuracy: ≤0.01mm
- Seal Type: S10BH (Double-sided metal scraper + End seals)
- Material: Carbon steel rail with chrome plating / Aluminum alloy carriage
- Operating Temperature: -20℃ to 80℃
- Protection Class: IP54 (Dust-resistant & splash-proof)
- Lubrication: Pre-lubricated with lithium grease, maintenance interval: 1,000km travel
- Weight: 0.48kg (rail) + 0.22kg (carriage) = 0.7kg total
- Dimensions: 140mm(L) × 12mm(Rail W) × 15mm(H) (Excluding mounting flanges)
- Mounting Hole Pattern: M3 threaded, 30mm spacing between centers
Ultra-compact linear motion solution combining 4-row ball recirculation design with 45° contact angle for balanced radial and axial loads. Features hardened steel rails (HRC58-62) and corrosion-resistant treatment. The BH suffix indicates enhanced sealing with stainless steel scrapers for harsh environments.
- Precision laboratory automation stages
- Medical imaging equipment sliding mechanisms
- 3D printer X/Y axis guidance systems
- Semiconductor wafer handling robots
- Optical lens adjustment modules
- Desktop CNC engraving machines
Installation guidelines:
Ensure rail parallelism ≤0.05mm/m using precision level during mounting.
Apply Loctite 243 to M3 mounting screws (2.0N·m torque limit).
Avoid side-load impacts - max permissible moment: 12.5N·m.
| Property | Property Value |
|---|---|
| sku | LRM12L1X120S10BH |
| Slide Rail Width | 12mm |
