Airtac LRM Miniature Linear Guide LRM12L1X120S10BPT
2. Anti-drop ball bearing retention mechanism for simplified installation and replacement
3. Japanese-manufactured steel balls ensuring superior sphericity and wear resistance (ISO3290 G10 compliant)
4. Enhanced oil-scraping wipers and upgraded dust-proof sealing system
5. Streamlined profile with concealed fasteners protecting sealing strips and eliminating large particulate contamination
Category: Linear Guides | Brand: AirTAC | Series: LRM
AirTAC LRM12L1X120S10BPT Miniature Linear Guide Specifications
- Model: LRM12L1X120S10BPT
- Rail width: 12mm
- Carriage type: L1 (standard length)
- Stroke length: 120mm
- Accuracy grade: Normal (C) / High (H) optional
- Dynamic load capacity: 1,050N
- Static load capacity: 1,470N
- Material: Carbon steel with chromium plating (rail), Aluminum alloy (carriage)
- Sealing: Triple labyrinth seal + stainless steel scrapers
- Mounting hole pattern: 10mm spacing (M3 threaded)
- Operating temperature: -20℃ to 80℃
- Protection rating: IP54 standard (IP67 optional)
- Weight: 480g ±2% (complete assembly)
- Dimensions: 120mm(L) × 22.5mm(W) × 15.8mm(H)
Ultra-compact linear motion solution featuring dual-axis alignment capability and preloaded ball bearings (0.003-0.005mm clearance). Precision-ground rails achieve ±0.01mm/m straightness. Includes 4-row circular arc groove design for smooth motion and reduced vibration transmission. Compatible with automatic lubrication systems via grease nipple (M6×1).
- High-speed pick-and-place robotics (cycle rates up to 5Hz)
- Precision optical lens positioning systems
- Semiconductor wafer handling equipment
- Desktop CNC mill Z-axis guides
- Automated laboratory sample handlers
Installation tip:
Apply 32-38N·m torque during rail mounting. For maximum accuracy,
pre-chill rails to 5-10℃ below ambient temperature before
installation to compensate for thermal expansion.
| Property | Property Value |
|---|---|
| sku | LRM12L1X120S10BPT |
| Slide Rail Width | 12mm |
