Airtac LRM Miniature Linear Guide LRM12L1X120S10CP
2. Anti-drop ball bearing retention mechanism for simplified installation and replacement
3. Japanese-manufactured steel balls ensuring superior sphericity and wear resistance (ISO3290 G10 compliant)
4. Enhanced oil-scraping wipers and upgraded dust-proof sealing system
5. Streamlined profile with concealed fasteners protecting sealing strips and eliminating large particulate contamination
Category: Linear Guides | Brand: AirTAC | Series: LRM
AirTAC LRM12L1X120S10CP Miniature Linear Guide Rail Specifications
- Model: LRM12L1X120S10CP
- Type: Single-axis miniature linear motion guide
- Rail width: 12mm
- Block quantity: 1 carriage block
- Effective stroke: 120mm (±0.5mm tolerance)
- Accuracy grade: C (Normal precision)
- Dynamic load capacity: 1.25kN
- Static load capacity: 2.4kN
- Material: Stainless steel rail (SUS440C) / Aluminum alloy block
- Seal type: Double-lip contact seals + scraper
- Operating temperature: -10℃ to 80℃
- Mounting hole type: Counterbored holes (M4×0.7 thread)
- Repeat positioning accuracy: ±0.005mm
- Max speed: 2m/s (with lubrication)
- Protection rating: IP54
- Weight: 680g ±2% (complete assembly)
- Dimensions: 120mm(L) × 22mm(W) × 14.5mm(H) (rail only)
- Block dimensions: 34mm(L) × 12mm(W) × 19mm(H)
Ultra-compact linear guide system optimized for space-constrained precision applications. Features chromium-plated raceways with ball recirculation design for smooth motion and minimal friction loss. Preloaded ball bearings provide zero backlash operation. Includes mounting reference edges for simplified alignment.
- High-speed PCB component placement machines
- Medical diagnostic equipment sliding mechanisms
- Semiconductor wafer inspection stages
- 3D printer X/Y axis systems
- Laboratory automation sample handlers
Installation note:
Clean rail surfaces with IPA before assembly. Use torque-controlled driver for M4 mounting screws (recommended 1.2N·m).
Apply lithium soap-based grease (NLGI #2) through Zerk fittings every 500km travel. Avoid side-load impacts exceeding 150N.
| Property | Property Value |
|---|---|
| sku | LRM12L1X120S10CP |
| Slide Rail Width | 12mm |
