Airtac LRM Miniature Linear Guide LRM12L1X140S10AH
2. Anti-drop ball bearing retention mechanism for simplified installation and replacement
3. Japanese-manufactured steel balls ensuring superior sphericity and wear resistance (ISO3290 G10 compliant)
4. Enhanced oil-scraping wipers and upgraded dust-proof sealing system
5. Streamlined profile with concealed fasteners protecting sealing strips and eliminating large particulate contamination
Category: Linear Guides | Brand: AirTAC | Series: LRM
AirTAC LRM12L1X140S10AH Miniature Linear Guide Specifications
- Model: LRM12L1X140S10AH
- Series: LRM (Micro Rail System)
- Rail width: 12mm
- Carriage length: 45mm
- Effective stroke: 140mm
- Dynamic load capacity (C): 1.2kN
- Static load capacity (C0): 0.6kN
- Precision grade: Normal class (±15μm/100mm)
- Material: Carbon steel (SCM435) rails with aluminum alloy carriage
- Sealing: Triple labyrinth seal + stainless steel scraper
- Mounting hole spacing: 30mm (longitudinal) × 25mm (transverse)
- Operating temperature: -20℃ to 100℃
- Protection rating: IP54 (dust resistant & water spray protected)
- Weight: 0.45kg (complete assembly)
- Dimensions: 180mm(L) × 12mm(W) × 15mm(H) (rail length = stroke + carriage length)
Ultra-compact linear motion solution featuring hardened raceways (HRC58-62) and preloaded ball bearings for near-zero backlash. The asymmetric carriage design optimizes moment load capacity while maintaining 80% reduced size compared to standard guides. Integrated oil retention grooves enable continuous lubrication cycles.
- Medical probe positioning mechanisms
- Laboratory sample handling robots
- Desktop 3D printer X/Y axes
- Optical lens alignment stages
- Semiconductor wafer inspection equipment
Installation note:
Requires mounting surface flatness ≤0.01mm/m. Use M3×6mm flathead screws torqued to 0.8-1.2N·m.
Apply ISO VG32-68 grease to lubrication ports every 100km travel. Avoid axial impacts exceeding 50m/s².
| Property | Property Value |
|---|---|
| sku | LRM12L1X140S10AH |
| Slide Rail Width | 12mm |
