Airtac LRM Miniature Linear Guide LRM12L1X145S10BP
2. Anti-drop ball bearing retention mechanism for simplified installation and replacement
3. Japanese-manufactured steel balls ensuring superior sphericity and wear resistance (ISO3290 G10 compliant)
4. Enhanced oil-scraping wipers and upgraded dust-proof sealing system
5. Streamlined profile with concealed fasteners protecting sealing strips and eliminating large particulate contamination
Category: Linear Guides | Brand: AirTAC | Series: LRM
AirTAC LRM12L1X145S10BP Micro Linear Guide Specifications
- Model Decoding: LRM12-L1-X145-S10-BP
- LRM12: Rail width 12mm series
- L1: Single slider configuration
- X145: Effective stroke length 145mm
- S10: Preload class C0 (light preload)
- BP: Stainless steel end caps + wiper seals
- Structure: 4-row circular ARC contact design
- Rail width: 12mm (±0.002mm tolerance)
- Slider quantity: 1 unit per rail
- Effective travel: 145mm (usable stroke)
- Accuracy grade: Normal grade (≤18μm/300mm)
- Load capacity:
- Dynamic radial load: 490N
- Dynamic moment load (Mx/My): 15.7Nm
- Static radial load: 1,470N
- Material:
- Rail: Chrome-plated bearing steel (HRC58-62)
- Slider: Anodized aluminum alloy
- Sealing: Triple labyrinth seal + non-contact scrapers
- Mounting hole spacing: 30mm pitch (M3 threaded)
- Temperature range: -20℃ to 100℃
- Protection rating: IP54 (dust protected & splash resistant)
- Weight: 650g ±2% (rail + slider assembly)
- Dimensions:
- Rail length: 190mm (total including mounting ends)
- Slider dimensions: 45mm(L) × 28mm(W) × 15mm(H)
- Package size: 205mm × 35mm × 20mm
Ultra-compact linear motion solution featuring hybrid ceramic balls (G5 grade) for smooth micron-level positioning. The hardened rail surface (0.5-0.8μm Ra roughness) ensures long-term wear resistance, while the optimized recirculation system reduces vibration harmonics by 40% compared to standard models. Requires periodic lubrication with ISO VG15-grade grease.
- High-precision medical analyzers (PCR machines, sample handlers)
- Semiconductor wafer inspection equipment stages
- Miniature CNC engraving tool Z-axis mechanisms
- Optical lens alignment systems in photolithography
- Laboratory automation liquid handling robots
Mounting protocol:
Achieve ≤0.02mm/m parallelism between rails using laser alignment.
Apply 0.6-0.8Nm torque for M3 fasteners. Break-in with 50 cycles
at 10% rated load before full operation.
| Property | Property Value |
|---|---|
| sku | LRM12L1X145S10BP |
| Slide Rail Width | 12mm |
