Airtac LSH Linear Guide Rail LSH15BK-F1N-N-E-M4
2. High Rigidity Four-Directional Equal Load Design: Incorporates 4-row ball circuits with 45° contact angle configuration, achieving optimal two-point contact for bidirectional radial/lateral load capacity. Optional preload application enhances system rigidity when required.
3. Interchangeability: Stringent manufacturing precision ensures dimensional consistency within stable tolerances. Integrated retainer design prevents ball dislodgement, enabling between and matching guideways while preserving operational smoothness, preload integrity, and motion accuracy.
Category: Linear Guides | Brand: AIRTAC | Series: LSH
AirTAC LSH15BK-F1N-N-E-M4 Linear Guide Rail Specifications
- Model: LSH15BK-F1N-N-E-M4
- Type: Miniature linear guide rail with block
- Rail width: 15mm
- Block type: LSH15BK (Flange-mounted type)
- Accuracy grade: Normal (N)
- Preload level: E (Light preload)
- Seal system: Double-sided wiper + End seals
- Mounting hole spacing: 30mm (Longitudinal) × 23mm (Transverse)
- Block dimensions: 53mm(L) × 34.5mm(W) × 25mm(H)
- Rail height: 15mm
- Ball diameter: 2.381mm (3/32")
- Dynamic load rating (C): 3.35kN
- Static load rating (C0): 5.6kN
- Weight per unit:
- Block: 0.18kg
- Rail (per meter): 1.8kg/m
- Standard rail lengths: 100mm to 4000mm (customizable)
- Material: High-carbon chromium bearing steel (SUJ2 equivalent)
- Surface hardness: HRC 58-62
- Operating temperature: -20℃ to 100℃
- Protection rating: IP54 (Dust-protected & water splash resistant)
Precision linear motion solution combining compact design with high rigidity. Features optimized ball circulation for smooth movement and reduced noise (≤45dB at 1m/s). The M4 mounting screws enable secure fixation in space-constrained applications. Includes corrosion-resistant treatment for industrial environments.
- High-speed PCB drilling machines
- Medical imaging equipment sliding mechanisms
- 3D printer X/Y axis motion systems
- Automated optical inspection (AOI) stages
- Semiconductor wafer handling robots
Installation guidance:
Apply 5-7N·m torque to M4 mounting screws. Use 0.5-1.0mm pre-travel gap between rail ends.
Lubricate with ISO VG15-32 grease every 100km of travel or 6 months.
| Property | Property Value |
|---|---|
| sku | LSH15BK-F1N-N-E-M4 |
| Slider Width | <15mm> |
| Slide Block Type | Flange Locking Style |
