Airtac LSH Linear Guide Rail LSH15BK-F1N-P-D-M4
2. High Rigidity Four-Directional Equal Load Design: Incorporates 4-row ball circuits with 45° contact angle configuration, achieving optimal two-point contact for bidirectional radial/lateral load capacity. Optional preload application enhances system rigidity when required.
3. Interchangeability: Stringent manufacturing precision ensures dimensional consistency within stable tolerances. Integrated retainer design prevents ball dislodgement, enabling between and matching guideways while preserving operational smoothness, preload integrity, and motion accuracy.
Category: Linear Guides | Brand: AIRTAC | Series: LSH
AirTAC LSH15BK-F1N-P-D-M4 Linear Guide Rail Specifications
- Model: LSH15BK-F1N-P-D-M4
- Type: Precision miniature linear guide system
- Rail width: 15mm
- Carriage quantity: Single block (standard)
- Rail length customization: 100-2000mm (standard stock lengths available)
- Dynamic load capacity (C): 3.5kN
- Static load capacity (C0): 5.6kN
- Precision grade: Normal (N) / High (H) optional
- Seal type: Triple-lip contact seals with dust-resistant design
- Ball diameter: 2.381mm (3/32")
- Recirculation system: 4-row circular groove design
- Mounting hole pattern: M4×0.7 threaded holes @ 20mm spacing
- Material: Carbon steel with black oxide coating (stainless steel optional)
- Operating temperature: -20℃ to 100℃
- IP rating: IP54 (standard seals)
- Weight per 100mm rail: 0.45kg
- Carriage dimensions: 24mm(W) × 50mm(L) × 19mm(H)
High-rigidity miniaturized linear guide optimized for space-constrained automation systems. Features corrosion-resistant treatment and preloaded ball bearings (F1N class) for minimal deflection under moment loads. Compatible with automatic lubrication systems through grease nipple ports.
- PCB drilling/routing machine Z-axis guidance
- Medical device component positioning stages
- Semiconductor wafer handling robots
- High-speed pick-and-place X-Y systems
- Precision optical alignment equipment
Installation note:
Requires surface flatness ≤0.01mm/m and parallelism ≤0.02mm between paired rails.
Use torque-controlled tightening (0.7-0.9Nm for M4 screws) with sequential diagonal pattern.
Maintenance:
Relubricate every 100km travel or 6 months with ISO VG32-68 grease.
Avoid mixing lubricant types without thorough cleaning.
| Property | Property Value |
|---|---|
| sku | LSH15BK-F1N-P-D-M4 |
| Slider Width | <15mm> |
| Slide Block Type | Flange Locking Style |
