Airtac LSH Linear Guide Rail LSH15BK-F1N-P-E-M4
2. High Rigidity Four-Directional Equal Load Design: Incorporates 4-row ball circuits with 45° contact angle configuration, achieving optimal two-point contact for bidirectional radial/lateral load capacity. Optional preload application enhances system rigidity when required.
3. Interchangeability: Stringent manufacturing precision ensures dimensional consistency within stable tolerances. Integrated retainer design prevents ball dislodgement, enabling between and matching guideways while preserving operational smoothness, preload integrity, and motion accuracy.
Category: Linear Guides | Brand: AIRTAC | Series: LSH
AirTAC LSH15BK-F1N-P-E-M4 Linear Guide Rail Specifications
- Model: LSH15BK-F1N-P-E-M4
- Series: LSH (Low-Noise Super High Rigidity)
- Rail width: 15mm
- Block type: BK (Standard Flange with 4 Mounting Holes)
- Preload grade: F1N (Light Preload: 3-5% Ca)
- Accuracy class: P (High Precision ±0.02mm/300mm)
- Sealing type: E (Triple-Lip Seal + Metal Scraper)
- Mounting hole size: M4 (4mm Thread Diameter)
- Roller material: SUJ2 Bearing Steel (HRC 58-62)
- Rail material: Carbon Steel (SCM435, Induction Hardened)
- Dynamic load capacity (C): 6.5kN
- Static load capacity (C0): 9.8kN
- Max travel speed: 5m/s
- Operating temperature: -20℃ to 100℃
- Weight per meter: 1.45kg/m
- Standard rail length: 100-4000mm (Customizable)
- Block dimensions: 62mm(L) × 34mm(W) × 24.5mm(H)
- Rail cross-section: 15mm(W) × 18mm(H)
- Mounting hole spacing: 40mm longitudinal, 30mm transverse
Precision linear motion system featuring optimized raceway geometry for smooth operation under high moment loads. The triple-seal design provides IP54 dust/water resistance, with stainless steel scrapers protecting against chip intrusion. Preloaded ball bearings ensure minimal deflection during bidirectional movement.
- High-speed CNC tool changer mechanisms
- Semiconductor wafer handling robots
- Laser cutting machine X/Y axes
- Automated optical inspection (AOI) equipment
- Precision grinding machine slides
Installation guidelines:
Mount on machined reference surface (Flatness ≤0.01mm/100mm).
Use torque-controlled tightening sequence (M4 bolts at 1.2-1.5N·m).
Apply lithium soap-based grease to rail before first operation.
| Property | Property Value |
|---|---|
| sku | LSH15BK-F1N-P-E-M4 |
| Slider Width | <15mm> |
| Slide Block Type | Flange Locking Style |
