Airtac LSH Linear Guide Rail LSH15BK-F2N-H-C-M4
2. High Rigidity Four-Directional Equal Load Design: Incorporates 4-row ball circuits with 45° contact angle configuration, achieving optimal two-point contact for bidirectional radial/lateral load capacity. Optional preload application enhances system rigidity when required.
3. Interchangeability: Stringent manufacturing precision ensures dimensional consistency within stable tolerances. Integrated retainer design prevents ball dislodgement, enabling between and matching guideways while preserving operational smoothness, preload integrity, and motion accuracy.
Category: Linear Guides | Brand: AIRTAC | Series: LSH
AirTAC LSH15BK-F2N-H-C-M4 Linear Guide Rail Specifications
- Model Code Breakdown: LSH15 (Series) | BK (Black oxide coating) | F2N (Flanged block with 2 nuts) | H (High preload) | C (Standard length code) | M4 (Mounting hole size)
- Rail Width: 15mm
- Block Dimensions: 55mm(L) × 34.5mm(W) × 24.5mm(H)
- Rail Height: 19mm
- Ball Circuit: 4 rows (2 per side)
- Dynamic Load Capacity (C): 7.8kN
- Static Load Capacity (C0): 11.5kN
- Precision Grade: Normal (C) with ±50μm/m accuracy
- Weight per Meter (Rail): 1.45kg/m
- Block Weight: 0.23kg
- Mounting Hole Pattern: 60mm spacing (M4×0.7 threaded)
- Material: Carbon steel with black oxide treatment
- Sealing: Triple labyrinth seals + stainless steel scrapers
- Operating Temperature: -20℃ to 80℃
- Max Speed: 5m/s
- Lubrication: Pre-lubed with AFT-1D grease (relubrication every 1,000km)
High-rigidity miniaturized linear guide optimized for space-constrained precision applications. Features enhanced dust resistance through multi-stage sealing and corrosion-resistant surface treatment. The H-grade preload ensures minimal deflection under moment loads, making it ideal for robotic joints or vertical Z-axis applications.
- Desktop CNC milling machine slides
- Semiconductor wafer handling robots
- High-speed PCB drilling equipment
- Automated optical inspection (AOI) systems
- Precision 3D printer gantry systems
Installation tip:
Use torque-controlled tightening (0.7-0.9Nm for M4 screws) and sequential
fastening pattern to prevent rail deformation. Maintain 0.02mm/m parallelism
during rail alignment using laser measurement tools.
| Property | Property Value |
|---|---|
| sku | LSH15BK-F2N-H-C-M4 |
| Slider Width | <15mm> |
| Slide Block Type | Flange Type Bottom Lock Style |
