Airtac LSH Linear Guide Rail LSH15BK-F2N-H-E-M4
$45.35
Regular price
$52.85
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
LSH15BK-F2N-H-E-M4
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Self-aligning Capability: Features front-mounted X-type (45°×45°) arc raceway groove design with automatic alignment compensation. The internal mechanism absorbs minor mounting surface deviations to maintain high-precision, smooth, and stable linear motion.
2. High Rigidity Four-Directional Equal Load Design: Incorporates 4-row ball circuits with 45° contact angle configuration, achieving optimal two-point contact for bidirectional radial/lateral load capacity. Optional preload application enhances system rigidity when required.
3. Interchangeability: Stringent manufacturing precision ensures dimensional consistency within stable tolerances. Integrated retainer design prevents ball dislodgement, enabling between and matching guideways while preserving operational smoothness, preload integrity, and motion accuracy.
Category: Linear Guides | Brand: AIRTAC | Series: LSH
Installation note:
Use torque-controlled wrench (recommended 1.2N·m for M4 screws) and align
reference edges within 0.05mm/m. Apply lithium-based grease to rail
before first operation.
2. High Rigidity Four-Directional Equal Load Design: Incorporates 4-row ball circuits with 45° contact angle configuration, achieving optimal two-point contact for bidirectional radial/lateral load capacity. Optional preload application enhances system rigidity when required.
3. Interchangeability: Stringent manufacturing precision ensures dimensional consistency within stable tolerances. Integrated retainer design prevents ball dislodgement, enabling between and matching guideways while preserving operational smoothness, preload integrity, and motion accuracy.
Category: Linear Guides | Brand: AIRTAC | Series: LSH
AirTAC LSH15BK-F2N-H-E-M4 Linear Guide Rail Specifications
- Full model code: LSH15BK-F2N-H-E-M4
- Series: LSH (Miniature Linear Guide)
- Rail width: 15mm
- Block length: 72mm
- Height (rail + block): 24mm
- Ball circuit type: 4-row circular arc groove
- Preload level: H (Medium-high preload)
- Accuracy grade: Normal (C) / High (H) optional
- Dynamic load capacity: 1.5kN
- Static load capacity: 4.2kN
- Seal type: E (Double-sided metal scraper + rubber seals)
- Mounting hole spacing: 40mm (longitudinal) × 30mm (transverse)
- Fastener specification: M4×8 mounting screws
- Material: Carbon steel with black oxide coating
- Operating temperature: -20℃ to 100℃
- Block weight: 0.25kg
- Rail weight: 1.8kg/m
- Package dimensions (single set): 300mm(L) × 45mm(W) × 35mm(H)
Precision-ground linear motion system featuring corrosion-resistant treatment and multi-layer sealing. The F2N flange design enables both horizontal and vertical mounting configurations. Optimized for applications requiring compact dimensions with enhanced moment load capacity.
Ideal Applications:
- Desktop CNC router axis guidance
- 3D printer gantry systems
- Semiconductor wafer handling robots
- Medical analyzer sliding mechanisms
- Precision optical stage movement
Installation note:
Use torque-controlled wrench (recommended 1.2N·m for M4 screws) and align
reference edges within 0.05mm/m. Apply lithium-based grease to rail
before first operation.
| Property | Property Value |
|---|---|
| sku | LSH15BK-F2N-H-E-M4 |
| Slider Width | <15mm> |
| Slide Block Type | Flange Type Bottom Lock Style |
