Airtac LSH Linear Guide Rail LSH15BK-F2N-N-E-M4
2. High Rigidity Four-Directional Equal Load Design: Incorporates 4-row ball circuits with 45° contact angle configuration, achieving optimal two-point contact for bidirectional radial/lateral load capacity. Optional preload application enhances system rigidity when required.
3. Interchangeability: Stringent manufacturing precision ensures dimensional consistency within stable tolerances. Integrated retainer design prevents ball dislodgement, enabling between and matching guideways while preserving operational smoothness, preload integrity, and motion accuracy.
Category: Linear Guides | Brand: AIRTAC | Series: LSH
AirTAC LSH15BK-F2N-N-E-M4 Linear Guide Rail Specifications
- Model: LSH15BK-F2N-N-E-M4
- Series: LSH Miniature Linear Guide
- Rail width: 15mm
- Block width: 24mm
- Standard length options: 500/1000/1500mm (customizable)
- Preload level: F2N (Medium preload)
- Accuracy grade: E (Normal precision ±0.02mm/300mm)
- Dynamic load rating (C): 3.5kN
- Static load rating (C0): 5.2kN
- Ball diameter: 2.381mm
- Ball circuit count: 4-row circular groove
- Mounting hole spacing: 40mm (longitudinal), 30mm (transverse)
- Mounting screw: M4×8 (ISO 4762)
- Material: Carbon chromium bearing steel (SUJ2 equivalent)
- Surface treatment: Black oxide coating
- Operating temperature: -20℃ to 80℃
- Weight: 1.2kg/m (rail only), 0.35kg (block)
- Dimensions (block): 64mm(L) × 24mm(W) × 15mm(H)
High-rigidity miniature linear guide with optimized load distribution, featuring corrosion-resistant oxidation treatment. The F2N preload ensures vibration damping for smooth motion control. Integrated sealing strips prevent particulate ingress (IP54 equivalent). Compatible with automated lubrication systems.
- Precision CNC engraving machine Z-axis
- Semiconductor wafer handling robots
- Laser cutting equipment linear stages
- High-speed pick-and-place assembly systems
- Medical imaging device sliding mechanisms
Installation note:
Use 0.01mm/m grade straightedge for alignment. Tighten M4 screws
in cross pattern at 1.2N·m torque. Apply lithium soap-based grease
(NLGI #2) during assembly.
| Property | Property Value |
|---|---|
| sku | LSH15BK-F2N-N-E-M4 |
| Slider Width | <15mm> |
| Slide Block Type | Flange Type Bottom Lock Style |
