Airtac LSH Linear Guide Rail LSH15BK-F2N-P-B-M4
2. High Rigidity Four-Directional Equal Load Design: Incorporates 4-row ball circuits with 45° contact angle configuration, achieving optimal two-point contact for bidirectional radial/lateral load capacity. Optional preload application enhances system rigidity when required.
3. Interchangeability: Stringent manufacturing precision ensures dimensional consistency within stable tolerances. Integrated retainer design prevents ball dislodgement, enabling between and matching guideways while preserving operational smoothness, preload integrity, and motion accuracy.
Category: Linear Guides | Brand: AIRTAC | Series: LSH
AirTAC LSH15BK-F2N-P-B-M4 Linear Guide Rail Specifications
- Model: LSH15BK-F2N-P-B-M4
- Type: Precision linear guide rail with ball recirculation
- Rail width: 15mm
- Slider length: 50mm
- Standard rail length options: 100mm to 2000mm (customizable)
- Dynamic load rating (C): 3.5kN
- Static load rating (C0): 7.8kN
- Accuracy grade: Normal (P) ±5μm/m
- Preload level: F2N (medium preload)
- Seal type: B (double-sided wipers + end seals)
- Mounting hole specification: M4×8mm (30mm pitch spacing)
- Material: Carbon steel with chrome-plated rail
- Operating temperature: -20℃ to 80℃
- Protection rating: IP54
- Rail weight: ~0.8kg/m
- Slider weight: 0.25kg
- Slider dimensions (W×H×L): 34mm × 24mm × 50mm
- Rail dimensions (W×H): 15mm × 18mm
A high-rigidity linear motion solution featuring optimized ball groove geometry for smooth operation (≤45dB noise level). The corrosion-resistant chrome plating and multi-layered sealing system ensure durability in harsh environments. Includes pre-drilled mounting holes with alignment marks for simplified installation.
- CNC machine tool Z-axis guidance systems
- High-speed pick-and-place robotic arms
- Semiconductor wafer handling equipment
- Precision optical instrument stages
- Automated packaging line conveyors
Installation note:
Clean rail surfaces with non-linting cloth before assembly. Use 0.7-0.9Nm torque for M4 mounting screws.
Align rails within 0.02mm/m parallelism tolerance using precision level. Apply ISO VG32-68 grease during maintenance.
| Property | Property Value |
|---|---|
| sku | LSH15BK-F2N-P-B-M4 |
| Slider Width | <15mm> |
| Slide Block Type | Flange Type Bottom Lock Style |
