Airtac LSH Linear Guide Rail LSH15BK-F2N-P-C-M4
The AirTAC Airtac LSH Linear Guide Rail LSH15BK-F2N-P-C-M4 is a standard-type profile linear guide on a 15 mm wide rail. Four rows of balls contact X-shaped raceways at a 45° angle, so the guide carries load equally in all four directions and absorbs small mounting errors inside the carriage instead of binding.
- SeriesLSH
- Supplied asCarriage / block only
- SizeLSH15
- Rail width15 mm
- Carriage lengthStandard carriage
- AccuracyP — precision grade
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac LSH Linear Guide Rail LSH15BK-F2N-P-C-M4
A single LSH15 F2 carriage in precision grade: flange mounting from underneath, standard body length, M4 nipple for greasing. This listing is the block by itself - the profile rail is not part of the order. Inside, balls recirculate through four rows of X-arranged 45 degree raceways with two contact points per ball, so downward, lift-off and side loads all land on the same rating, and small datum errors are absorbed rather than forced into a bind. The LSH15 size runs on a rail 15 mm wide.
On paper: 11.3 kN dynamic, 17.9 kN static, 0.12 kN.m on all three moment axes. The static-to-dynamic ratio near 1.6 is why short-stroke shock loads rarely trouble this size, while travel life follows C. P grade holds running parallelism between 3 and 21 um across the rail-length bands. As a carriage-only purchase it costs roughly a quarter of a complete set, which is why a worn block is usually renewed rather than the whole guide.
Airtac LSH Linear Guide Rail LSH15BK-F2N-P-C-M4 Technical Specifications
| Model | Airtac LSH Linear Guide Rail LSH15BK-F2N-P-C-M4 |
|---|---|
| Series | LSH Series Linear Guide |
| Supplied as | Carriage / block only |
| Construction | Recirculating ball, four ball rows on X-shaped raceways at a 45° contact angle, self-aligning |
| Size code | LSH15 |
| Rail width | 15 mm |
| Carriage style | Flange, bottom mounting |
| Carriage length | Standard carriage |
| Basic dynamic load rating C | 11.3 kN per carriage |
|---|---|
| Basic static load rating C0 | 17.9 kN per carriage |
| Allowable static moment | MR 0.12 / MP 0.12 / My 0.12 kN·m |
| Accuracy grade | P — precision grade |
| Mounting screws | M4 — 412 N·cm into steel, 274 cast iron, 206 aluminium |
| Lubrication | Pre-filled with Mobilux EP2; re-grease every 100 km of travel or every 3–6 months |
| Interchangeability | LSH carriages fit LSH rails of the same model, matched by the pairing code |
Specifications follow the official AirTAC LSH catalogue. The catalogue page does not state the carriage or rail base material. Sizes 35 and 45 exist in the catalogue but are not stocked here; they are available to order. This item is a carriage only. Order a complete set if you also need a rail.
Model Code: Airtac LSH Linear Guide Rail LSH15BK-F2N-P-C-M4
| LSH | LSH Series Linear Guide. |
|---|---|
| 15 | Size code. |
| BK | Carriage / block only — no rail supplied. |
| H / F1 / F2 / F3 | Carriage style: square, or flange mounted from the top, bottom, or both. |
| N | Standard carriage. |
| P | P — precision grade. |
| Pairing code | Rails and carriages must share a pairing code. Take it from the original part when replacing. |
| -M4 / -M6 / -A01… | Grease nipple or tube-fitting type. Restricted by size: size 15 the M4 family, 20–35 the M6 family, 45 the PT1/8 family. |
What Is In The Box
| This order | Carriage / block only |
|---|---|
| Rail | No — not supplied with this item |
| Carriage | Yes, one |
This is a carriage on its own. NO RAIL IS INCLUDED. If you are not sure which form you need, send us the machine or the original part number and we will confirm it before you order.
Where the Airtac LSH Linear Guide Rail LSH15BK-F2N-P-C-M4 Is Used
Wafer probing station carriage swap
Probe stations in a university cleanroom are rebuilt block by block. This precision-grade carriage replaces a scored unit without touching the matched rail, provided the pairing letter C on both parts agrees.
LED inspection camera gantry
A camera riding above the guide needs the top surface; the F2 flange mounts from underneath so the lens plate bolts straight on. Moment ratings of 0.12 kN.m on every axis carry the cantilevered head.
High-cycle pick-and-place head
An axis with a 300 mm stroke cycling once per second covers 100 km in about two weeks, so the distance-based regrease interval binds long before the calendar - one more reason a serviceable M4 nipple on a spare block earns its keep.
Is the Airtac LSH Linear Guide Rail LSH15BK-F2N-P-C-M4 the Right Guide?
Start with the form: this is carriage only, so it suits a repair or a build where the rail already exists. Size on both load and moment - for a cantilever the MR figure usually decides, and moving to an LSH20 block buys moment capacity faster than it buys dynamic rating. Light-duty compact machines can drop to LRM, whose ratings are unpublished and confirmed by us per application; short-travel axes wanting crossed-roller stiffness can cross to LGC instead.
Checklist for the order: F2 bottom flange, standard length, P accuracy, M4 fitting, and pairing code C appearing on both block and rail. Remember preload is only an option on complete set codes, and a tighter grade always costs installation latitude on the mounting surface.
Quick checklist
- ✓ Complete set, carriage only, or rail only?
- ✓ Worst-case moment, not just straight load
- ✓ Travel length and mounting space
- ✓ Accuracy grade and preload
- ✓ Mounting surface ground or finish-milled
- ✓ Pairing code, if replacing a part
Installation & Maintenance Notes
- check Mounting surface must be ground or finish-milled.
- check Torque the rail screws per the recommended figures, in sequence.
- check Keep the mounting corner radius inside the stated R maximum.
- check Do not angle the carriage onto the rail; balls can drop out.
- check Drive the supplied bolt caps into the mounting holes.
- check Re-grease every 100 km of travel or every 3–6 months.
- check Installation by qualified personnel per AirTAC docs.
Airtac LSH Linear Guide Rail LSH15BK-F2N-P-C-M4 FAQ
C is 11.3 kN and C0 is 17.9 kN per block; the moment ratings read 0.12/0.12/0.12 kN.m for MR/MP/My. Running parallelism for P grade lies in the 3-21 um band. Use M4 screws torqued to 412 N.cm (steel), 274 N.cm (cast iron) or 206 N.cm (aluminium). Grease holds 0.9 cm3 new and takes 0.3 cm3 at re-fill; service it at 100 km of travel or every 3-6 months, whichever comes first.
Nothing but the carriage ships on this code - there is no rail in the box. The pairing letter C ties this block to a rail carrying the same letter, so quote the code printed on your old carriage or rail when ordering. Interchangeability runs within LSH only: a C-coded LSH15 block will not mate with another maker's 15 mm rail.
