Airtac LSH Linear Guide Rail LSH15BK-HN-H-C-M4
2. High Rigidity Four-Directional Equal Load Design: Incorporates 4-row ball circuits with 45° contact angle configuration, achieving optimal two-point contact for bidirectional radial/lateral load capacity. Optional preload application enhances system rigidity when required.
3. Interchangeability: Stringent manufacturing precision ensures dimensional consistency within stable tolerances. Integrated retainer design prevents ball dislodgement, enabling between and matching guideways while preserving operational smoothness, preload integrity, and motion accuracy.
Category: Linear Guides | Brand: AIRTAC | Series: LSH
AirTAC LSH15BK-HN-H-C-M4 Linear Guide Rail Specifications
- Model: LSH15BK-HN-H-C-M4
- Series: LSH (Compact High-Rigidity Linear Guide)
- Rail Width: 15mm
- Block Type: BK (Standard Flanged Block)
- Preload Level: HN (Medium Preload)
- Accuracy Grade: H (High Precision ±50μm/1000mm)
- Seal Type: C (Combination Seal - Metal Scraper + Rubber)
- Mounting Hole Pattern: M4 (4mm Screw Thread)
- Dynamic Load Capacity (C): 6.2kN
- Static Load Capacity (C0): 9.8kN
- Roller Type: 4-Row Circular Arc Groove Ball Bearing System
- Material: Carbon Steel (SUJ2 Equivalent) with Black Oxide Coating
- Operating Temperature: -20℃ to 80℃
- Lubrication: Pre-lubricated with Lithium Soap Grease
- Recirculation System: Full-Circuit Optimized Path Design
- Weight per Unit:
- Block: 0.28kg
- Rail (per 100mm): 0.45kg
- Dimensions:
- Block Size: 62mm(L) × 24.5mm(W) × 15mm(H)
- Rail Height: 15mm
- Mounting Hole Spacing: 40mm longitudinal pitch
High-precision miniaturized linear guide featuring optimized ball contact angles (45°×45° arrangement) for balanced radial and lateral loads. Incorporates dust-resistant dual sealing system with stainless steel end seals and rubber wipers. The HN preload ensures minimal deflection during high-speed reciprocation (up to 5m/s). Compatible with automatic lubrication systems through integrated grease nipples.
- Precision CNC tool changer mechanisms
- Semiconductor wafer handling robots
- Medical imaging equipment sliding systems
- High-speed PCB drilling machines
- Automated optical inspection (AOI) stages
- 3D printer gantry positioning systems
Installation protocol:
Clean rail surfaces with non-lint cloth and alcohol before assembly.
Use torque-controlled wrench (0.7-0.9N·m for M4 screws) in cross pattern tightening sequence.
Maintain 0.02mm/m parallelism tolerance during rail alignment.
| Property | Property Value |
|---|---|
| sku | LSH15BK-HN-H-C-M4 |
| Slider Width | <15mm> |
| Slide Block Type | Square Body |
