Airtac LSH Linear Guide Rail LSH15BK-HN-N-B-M4
2. High Rigidity Four-Directional Equal Load Design: Incorporates 4-row ball circuits with 45° contact angle configuration, achieving optimal two-point contact for bidirectional radial/lateral load capacity. Optional preload application enhances system rigidity when required.
3. Interchangeability: Stringent manufacturing precision ensures dimensional consistency within stable tolerances. Integrated retainer design prevents ball dislodgement, enabling between and matching guideways while preserving operational smoothness, preload integrity, and motion accuracy.
Category: Linear Guides | Brand: AIRTAC | Series: LSH
AirTAC LSH15BK-HN-N-B-M4 Linear Guide Rail Specifications
- Model: LSH15BK-HN-N-B-M4
- Series: LSH Miniature Linear Guide
- Rail width: 15mm
- Block length: 53mm (standard)
- Preload level: HN (medium preload)
- Accuracy grade: Normal precision (N class)
- Seal type: B-type (double-sided wipers + end seals)
- Mounting hole pattern: M4 screws (30mm hole spacing)
- Dynamic load capacity (C): 3.35 kN
- Static load capacity (C0): 5.25 kN
- Max travel speed: 5 m/s
- Operating temperature: -20℃ to 100℃
- Material: Carbon steel with black oxide coating
- Weight per unit: 0.68kg (rail: 0.42kg/m; block: 0.26kg)
- Dimensions:
- Rail height: 12mm
- Block width: 24mm
- Block height: 15mm
- Standard rail lengths: 500/1000/1500mm (customizable)
Precision miniature linear guide system featuring optimized ball circuit design for smooth motion and high rigidity. The HN preload ensures minimal deflection under medium loads, while B-type sealing provides IP54-rated dust protection. Compatible with automatic lubrication systems through grease nipple ports.
- 3D printer X/Y axis positioning systems
- Laser cutting machine optical carriage
- Semiconductor wafer handling robots
- Medical imaging equipment sliding mechanisms
- PCB drilling machine feed units
Installation note:
Apply 25-30N·m torque for M4 mounting screws. Use alignment jig ATC-LSH15-ALIGN
during installation to ensure parallel tolerance ≤0.02mm/m. Run-in with ISO VG68
grease for initial 50 cycles before full load operation.
| Property | Property Value |
|---|---|
| sku | LSH15BK-HN-N-B-M4 |
| Slider Width | <15mm> |
| Slide Block Type | Square Body |
