Airtac M3PL Detent Rotary Button Mechanical Valve M3PL21006G
2. M3B, M3R, and M3L series utilize externally-provided shifting force for valve actuation, enabling position sensing or limit switch applications.
3. Manually actuated M3C, M3D, M3Y, M3PF, M3PM, M3PP, M3PL, and M3HS series feature multiple control head configurations optimized for diverse operating scenarios.
4. Spool-type construction with internal sealing ring ensures pressure-independent operation (backpressure-resistant), delivering reliable sealing performance and smooth directional switching.
5. Maintenance-free operation requiring no lubrication.
6. Multi-position mounting capability enables flexible installation configurations.
7. M3C, M3D, M3Y, M3R, and M3I series employ metal alloy control heads for extended service life and enhanced reliability in demanding environments.
Category: Mechanical Valves | Brand: Airtac | Series: M3PL Stationary Rotary Pushbutton Type
AirTAC M3PL21006G Parking Rotary Button Type Mechanical Valve Specifications
- Model: M3PL21006G
- Type: 3-position (Parking) / 5-port rotary mechanical valve
- Port configuration: P (pressure), A/B (actuator ports), R/S (exhausts)
- Port thread size: M5 × 0.8 (ISO standard)
- Operating pressure range: 0.2–1.0 MPa (29–145 psi)
- Max flow rate: 450 NL/min (ANR)
- Operating temperature: -5℃ to 60℃ (23℉ to 140℉)
- Actuation force: 3.5N ±0.5N at button center
- Rotation angle: 45° ±2° per switching position
- Body material: Glass fiber reinforced polyamide (PA66-GF30)
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Weight: 220g ±5g (including accessories)
- Dimensions: 54mm(W) × 44mm(H) × 38mm(D)
- Mounting: Panel mounting with M4 screws (2 places)
- IP rating: IP40 (finger-safe design)
- Cycle life: ≥500,000 operations
Manual override valve with tactile positioning feedback, featuring a unique detent mechanism for precise mid-position control. The dual exhaust structure ensures rapid cylinder response during directional changes. Optimized for dust-prone environments with internal particle shedding prevention design. Compatible with ISO 15407-1 standard pneumatic systems.
- Emergency stop override in automated assembly lines
- Manual mode switching for robotic gripper systems
- Position locking in material handling equipment
- Process debugging in semiconductor manufacturing tools
- Safety interlocks for press machine tooling
Installation note:
Ensure proper alignment of exhaust ports (R/S) with system venting paths.
Apply 0.5-0.8Nm torque during screw mounting to prevent body deformation.
Perform monthly lubrication of rotating shaft with silicone grease (JIS K2220 2# grade).
| Property | Property Value |
|---|---|
| sku | M3PL21006G |
| Position | 3-Port 2-Position |
| Port Size | PT1/8 |
