Airtac M3PM Mushroom Head Push Button Mechanical Valve M3PM11006RG
2. The M3B, M3R, and M3L series require external mechanisms to provide shifting force, enabling position detection or travel switch applications;
3. The M3C, M3D, M3Y, M3PF, M3PM, M3PP, M3PL, and M3HS series feature manual operation with diverse control head structural configurations for versatile usage across conditions;
4. Spool-type design ensures consistent control force independent of working pressure (zero backpressure interference). Internal circumferential sealing delivers leak-tight performance and smooth shifting;
5. Lubrication-free operation eliminates maintenance requirements;
6. Supports multiple mounting orientations for flexible installation;
7. M3C, M3D, M3Y, M3R, and M3I series incorporate metal control heads for enhanced durability and operational stability.
**Category**: Mechanical Valves | **Brand**: Airtac | **Series**: M3PM
AirTAC M3PM Mushroom Head Push Button Mechanical Valve M3PM11006RG Specifications
- Model: M3PM11006RG
- Type: 3/2-way normally closed (mechanical spring return)
- Port size: PT1/8 (M5 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Body material: Nickel-plated brass
- Seal material: NBR (Nitrile rubber)
- Temperature range: -20℃ to 70℃ (-4°F to 158°F)
- Actuation force: 3.5–4.5 kgf
- Mounting type: Direct panel mounting
- Button type: Ø30mm mushroom head (red/yellow options)
- Protection rating: IP65 (dust-tight & water jet resistant)
- Weight: 180g ±5g
- Dimensions: 45mm(L) × 30mm(W) × 40mm(H)
- Thread depth: 10mm (panel cutout Ø30.5mm)
- Mechanical life: ≥500,000 cycles
Manual emergency-stop valve with positive mechanical engagement, featuring a lockable twist-release mechanism for safety compliance. The chrome-plated brass stem ensures smooth operation under repeated use. Includes dual-color position indicator (red/yellow) for clear status visibility. Requires 0.5–1.2Nm torque for secure mounting.
- Emergency stop stations in production lines
- Pneumatic system maintenance lockout/tagout (LOTO)
- Manual override in automated packaging systems
- Training simulators for industrial equipment
- Mobile hydraulic platform safety controls
Installation note:
Mount on 1–3mm thick panels using included M5×16mm hex bolts.
Ensure full button depression clearance (min. 15mm behind panel).
Test emergency release weekly by pulling/twisting the mushroom head.
| Property | Property Value |
|---|---|
| sku | M3PM11006RG |
| Position | 3-Port 2-Position |
| Port Size | PT1/8 |
