Airtac M3PM Mushroom Head Push Button Mechanical Valve M3PM21008B
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. The M3B, M3R, and M3L series require external mechanisms to provide shifting force, enabling position detection or travel switch applications;
3. The M3C, M3D, M3Y, M3PF, M3PM, M3PP, M3PL, and M3HS series feature manual operation with diverse control head structural configurations for versatile usage across conditions;
4. Spool-type design ensures consistent control force independent of working pressure (zero backpressure interference). Internal circumferential sealing delivers leak-tight performance and smooth shifting;
5. Lubrication-free operation eliminates maintenance requirements;
6. Supports multiple mounting orientations for flexible installation;
7. M3C, M3D, M3Y, M3R, and M3I series incorporate metal control heads for enhanced durability and operational stability.
**Category**: Mechanical Valves | **Brand**: Airtac | **Series**: M3PM
AirTAC M3PM21008B Mushroom Head Push Button Mechanical Valve Specifications
- Model: M3PM21008B
- Type: 3/2-way normally closed (manual mechanical operation)
- Actuation style: Lockable mushroom head emergency stop design
- Port size: PT1/8 (G1/8 equivalent)
- Thread standard: ISO 228-1 (BSPP)
- Operating pressure: 0.05–0.9 MPa
- Max flow rate: 750 L/min (ANR)
- Body material: Nickel-plated brass
- Seal material: Heat-resistant NBR (+5℃ to +100℃)
- Button material: Stainless steel 304 with anti-slip grooves
- Mechanical life: ≥500,000 cycles
- Weight: 180g ±5g
- Dimensions: 38mm(W) × 38mm(D) × 48mm(H)
- Mounting: Direct panel mounting with M20×1.5 locknut
- Protection rating: IP67 (dust/water resistant)
- Compliance: CE/RoHS certified
Industrial-grade emergency stop valve featuring twist-to-release safety mechanism with 45N actuation force. The bright red mushroom head provides 360° accessibility with Ø40mm contact surface. Integrated spring return ensures automatic reset after emergency situations. Compatible with ISO 13850 safety standards.
- Production line emergency stop stations
- Plastic injection molding machine safety circuits
- CNC equipment pneumatic system cutoff
- Robotic workcell safety interlocks
- Hydraulic press two-hand control systems
- Training simulator emergency shutdowns
Installation guidelines:
Mount on minimum 2mm thick panels using included M20 locknut.
Maintain ≥25mm clearance around button perimeter for full accessibility.
Test monthly by pulling with 50-70N force to verify reset function.
| Property | Property Value |
|---|---|
| sku | M3PM21008B |
| Position | 3-Port 2-Position |
| Port Size | PT1/4 |
