Airtac M3PM Mushroom Head Push Button Mechanical Valve M3PM21008G
2. The M3B, M3R, and M3L series require external mechanisms to provide shifting force, enabling position detection or travel switch applications;
3. The M3C, M3D, M3Y, M3PF, M3PM, M3PP, M3PL, and M3HS series feature manual operation with diverse control head structural configurations for versatile usage across conditions;
4. Spool-type design ensures consistent control force independent of working pressure (zero backpressure interference). Internal circumferential sealing delivers leak-tight performance and smooth shifting;
5. Lubrication-free operation eliminates maintenance requirements;
6. Supports multiple mounting orientations for flexible installation;
7. M3C, M3D, M3Y, M3R, and M3I series incorporate metal control heads for enhanced durability and operational stability.
**Category**: Mechanical Valves | **Brand**: Airtac | **Series**: M3PM
AirTAC M3PM21008G Mushroom Head Push Button Mechanical Valve Specifications
- Model: M3PM21008G
- Type: 3/2-way normally closed (manual reset)
- Operation style: Mushroom head emergency stop (push-lock release)
- Port size: M5 × 0.8 (G1/8 thread equivalent)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Max flow rate: 350 NL/min (ANR)
- Body material: Nickel-plated brass
- Button material: Engineering plastic with UV resistance
- Seal material: HNBR rubber (-20℃ to 120℃)
- Mechanical life: ≥500,000 cycles
- Actuation force: 45N ± 5N
- Protection rating: IP67 (dust/water resistant)
- Weight: 220g ± 5g
- Dimensions: 48mm(L) × 48mm(W) × 76mm(H)
- Mounting: Panel mounting with M20×1.5 locknut
Emergency safety valve featuring a highly visible 40mm diameter red mushroom head with yellow base ring. Designed for instant system shutdown with positive latching mechanism requiring manual twist-release for reset. Corrosion-resistant construction with triple sealing (shaft, button base, and thread interfaces). Includes integrated mounting bracket for 10-20mm panel thickness.
- Production line emergency stop stations
- Injection molding machine safety cutoff
- CNC equipment panic shutdown systems
- Automated warehouse conveyor safety
- Robotic cell operator protection zones
Installation note:
Mount within 45° of vertical orientation. Apply thread sealant on male ports (PTFE tape not recommended).
Perform monthly button depression tests to prevent sticking. Requires 50mm clearance above button for full actuation travel.
| Property | Property Value |
|---|---|
| sku | M3PM21008G |
| Position | 3-Port 2-Position |
| Port Size | PT1/4 |
