Airtac M3Y Rocker Arm Type Mechanical Valve M3Y11006
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2、M3B, M3R, and M3L series utilize external mechanism-driven actuation, enabling dual functionality for position sensing and stroke switching applications.
3、Manual-operated series (M3C, M3D, M3Y, M3PF, M3PM, M3PP, M3PL, M3HS) feature diversified actuator head configurations optimized for varied operational requirements.
4、Spool-type design with pressure-independent control force (zero back-pressure effect), incorporating internal ring sealing for reliable leak-proof performance and responsive directional switching.
5、Maintenance-free operation without lubrication requirements.
6、Multi-position mounting capability ensures flexible system integration and simplified installation.
7、Metal actuator construction in M3C, M3D, M3Y, M3R, and M3I series delivers enhanced lifespan and operational stability under demanding conditions.
Category: Mechanical Valves | Brand: AIRTAC | Series: M3Y Rocker Arm Type
AirTAC M3Y11006 Lever-Operated Mechanical Valve Specifications
- Model: M3Y11006 (Roller Lever Type)
- Type: 3/2-way normally closed (mechanical actuation)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.05–1.0 MPa
- Max flow rate: 650 L/min (ANR)
- Actuation force: ≤5N lever operation force
- Weight: 220g ±5g
- Dimensions: 60mm(L) × 40mm(W) × 80mm(H)
- Body material: Die-cast aluminum alloy (anodized)
- Seal material: HNBR rubber (-20℃ to 120℃)
- Temperature range: -20℃ to 80℃ (with intermittent 100℃ peak)
- Port thread depth: 12mm (minimum engagement)
- Lever stroke: 15mm ±1mm
- Cycle life: ≥1 million operations
Manual override valve with roller-lever mechanism for precise tactile control in pneumatic systems. Features wear-resistant pivot bearings and dual-spring reset system. The chrome-plated lever arm prevents corrosion in humid environments. Compatible with ISO 15407-1 standards.
- Emergency stop systems in assembly lines
- Manual material handling equipment control
- Pneumatic fixture clamping verification
- Training simulators for industrial automation
- Lubrication system bypass control
Installation note:
Mount with lever movement plane parallel to operator access direction.
Apply thread sealant on port connections (PTFE tape not recommended).
Allow 30° minimum clearance for full lever rotation.
Requires mechanical impulse ≥2mm travel distance for reliable switching. For repetitive operations, install shock absorber when cycle rate exceeds 60CPM. Lubricate pivot point every 50,000 cycles using ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | M3Y11006 |
| Position | 3-Port 2-Position |
| Port Size | PT1/8 |
