Airtac MAC Stainless Steel Mini Air Cylinder MAC16X100SCA
1. Manufactured in compliance with AirTAC corporate standards;
2. Features custom bidirectional sealing profile with compact dimensions and integrated oil reservoir design for enhanced piston lubrication;
3. Equipped with fixed cushioning pads on both end caps to mitigate directional reversal impact;
4. Multiple rear cover configurations ensure versatile mounting flexibility;
5. Stainless steel barrel and end caps assembled through combined riveting and encapsulation process for robust connection;
6. Precision-engineered from high-grade stainless steel tubing offering exceptional corrosion resistance and structural integrity;
7. Comprehensive selection of cylinder specifications and mounting accessories available for customized applications;
8. Full-range magnetic version standard across series.
Category: Stainless Steel Miniature Cylinders | Brand: AirTAC | Series: MAC
AirTAC MAC16X100SCA Stainless Steel Mini Cylinder Specifications
- Model: MAC16X100SCA
- Type: Single-acting spring return (push type)
- Bore size: 16 mm
- Stroke: 100 mm
- Operating pressure: 0.05–1.0 MPa
- Operating temperature: -10℃ to 80℃
- Cushioning: Adjustable rubber buffer
- Port thread: M5×0.8 (standard) / G1/8 optional
- Material: Stainless steel (SUS304 barrel, CR rod)
- Seal material: NBR (standard) / FKM available
- Weight: 235 g ±5g
- Dimensions:
- Total length (retracted): 136 mm
- Body diameter: 26 mm
- Mounting base: 32×32 mm square
- Rod end thread: M6×1.0
- ISO standard: 6432 compliant
- Corrosion resistance: IP67 (rod extended)
High-precision miniaturized cylinder featuring full stainless steel construction for harsh environments. The through-rod design allows dual mounting orientations with anti-rotation stability. Optimized for high-speed applications (≤1.5 m/s) with precision-guided piston movement. Requires 5μm filtered dry air with ISO 8573-1:2010 class 4.3.2 air quality.
- Cleanroom automation in semiconductor manufacturing
- Food processing machinery (FDA-compliant variants)
- Pharmaceutical tablet pressing equipment
- Precision optical lens positioning systems
- Marine environment control systems
Installation note:
Lubricate rod with silicone grease (PSE2 grade) monthly in high-cycle applications.
Avoid side loads exceeding 2N·m. For vertical mounting, use model with spring-up orientation.
| Property | Property Value |
|---|---|
| sku | MAC16X100SCA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Stroke | 100mm |
