Airtac MAC Stainless Steel Mini Air Cylinder MAC16X100SCM
1. Manufactured in compliance with AirTAC corporate standards;
2. Features custom bidirectional sealing profile with compact dimensions and integrated oil reservoir design for enhanced piston lubrication;
3. Equipped with fixed cushioning pads on both end caps to mitigate directional reversal impact;
4. Multiple rear cover configurations ensure versatile mounting flexibility;
5. Stainless steel barrel and end caps assembled through combined riveting and encapsulation process for robust connection;
6. Precision-engineered from high-grade stainless steel tubing offering exceptional corrosion resistance and structural integrity;
7. Comprehensive selection of cylinder specifications and mounting accessories available for customized applications;
8. Full-range magnetic version standard across series.
Category: Stainless Steel Miniature Cylinders | Brand: AirTAC | Series: MAC
AirTAC MAC16X100SCM Stainless Steel Mini Cylinder Specifications
- Model: MAC16X100SCM
- Bore size: 16mm
- Stroke: 100mm
- Operating pressure: 0.05–1.0 MPa
- Operating temperature: -20℃ to 80℃
- Port size: M5×0.8 (standard), optional NPT1/8
- Cushioning: Adjustable rubber bumper (both ends)
- Rod thread: M6×1.0 (external)
- Material: Stainless steel (SUS304 barrel, SUS303 rod)
- Seal material: NBR + PU combination
- Weight: 280g ±5%
- Dimensions: 120mm(L) × 28mm(W) × 28mm(H)
- Mounting type: Basic type (optional foot/mid-flange)
- Protection rating: IP67 (standard wiper included)
- Lubrication: Pre-lubricated (recommended relube interval: 1,000km)
High-precision mini cylinder with full stainless steel construction offering superior corrosion resistance. Features a space-saving design with 28×28mm cross-section profile, ideal for clustered installations. Integrated anti-rotation mechanism prevents piston rod spin during operation. Compatible with magnetic sensors (sensor groove included).
- Clean room automation (semiconductor/FPD manufacturing)
- Food processing equipment with washdown requirements
- Medical device actuation systems
- High-humidity environments (marine/chemical applications)
- Precision positioning in robotics (SCARA arm tooling)
Installation guidelines:
Maintain 0.5-1mm clearance between cylinder body and mounting surface for thermal expansion.
Use copper-free grease (VGL120 equivalent) for relubrication. Avoid side loads exceeding 2N·m.
| Property | Property Value |
|---|---|
| sku | MAC16X100SCM |
| Rear Cover Type | Round Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Stroke | 100mm |
