Airtac MAC Stainless Steel Mini Air Cylinder MAC16X10SCA
$30.00
Regular price
$37.50
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MAC16X10SCA
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
MAC Stainless Steel Miniature Cylinder
1. Manufactured in compliance with AirTAC corporate standards;
2. Features custom bidirectional sealing profile with compact dimensions and integrated oil reservoir design for enhanced piston lubrication;
3. Equipped with fixed cushioning pads on both end caps to mitigate directional reversal impact;
4. Multiple rear cover configurations ensure versatile mounting flexibility;
5. Stainless steel barrel and end caps assembled through combined riveting and encapsulation process for robust connection;
6. Precision-engineered from high-grade stainless steel tubing offering exceptional corrosion resistance and structural integrity;
7. Comprehensive selection of cylinder specifications and mounting accessories available for customized applications;
8. Full-range magnetic version standard across series.
Category: Stainless Steel Miniature Cylinders | Brand: AirTAC | Series: MAC
Installation note:
Use anti-seize compound on stainless steel threads to prevent galling.
Maximum side load: 2.5N at full extension. For vertical mounting,
add 10% safety factor to required thrust calculations.
1. Manufactured in compliance with AirTAC corporate standards;
2. Features custom bidirectional sealing profile with compact dimensions and integrated oil reservoir design for enhanced piston lubrication;
3. Equipped with fixed cushioning pads on both end caps to mitigate directional reversal impact;
4. Multiple rear cover configurations ensure versatile mounting flexibility;
5. Stainless steel barrel and end caps assembled through combined riveting and encapsulation process for robust connection;
6. Precision-engineered from high-grade stainless steel tubing offering exceptional corrosion resistance and structural integrity;
7. Comprehensive selection of cylinder specifications and mounting accessories available for customized applications;
8. Full-range magnetic version standard across series.
Category: Stainless Steel Miniature Cylinders | Brand: AirTAC | Series: MAC
AirTAC MAC16X10SCA Stainless Steel Miniature Cylinder Specifications
- Model: MAC16X10SCA
- Bore size: 16mm
- Stroke: 10mm (±1mm adjustability)
- Material: Stainless steel (SUS304 barrel, SUS303 rod)
- Seal material: NBR/FKM optional
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 150℃ (with FKM seals)
- Cushioning type: Adjustable rubber buffer
- Mounting style: Dual male threads (M5×0.8 on both ends)
- Port size: PT1/8 (G1/8 optional)
- Rod rotation: 360° allowable
- Weight: 0.25kg (with standard fittings)
- Dimensions: 50mm(L) × 16mm(Ø) × 16mm(rod Ø)
- Protection rating: IP67 (dust/water resistant)
- Lubrication: Pre-lubricated (ISO VG32 equivalent)
High-precision corrosion-resistant cylinder with ultra-compact footprint, featuring magnetic piston for position sensing compatibility. The full stainless steel construction ensures exceptional durability in washdown environments. Integrated buffer adjustment screw allows fine-tuning of end-position damping.
Typical Applications:
- Pharmaceutical tablet pressing machines
- Food packaging line actuators
- Semiconductor wafer handling robots
- Marine equipment controls
- Cleanroom automation systems
Installation note:
Use anti-seize compound on stainless steel threads to prevent galling.
Maximum side load: 2.5N at full extension. For vertical mounting,
add 10% safety factor to required thrust calculations.
Maintenance:
Relubricate every 500km stroke travel using ISO VG32 turbine oil.
Replace rod wiper seal annually in high particulate environments.
| Property | Property Value |
|---|---|
| sku | MAC16X10SCA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Stroke | <10mm> |
