Airtac MAC Stainless Steel Mini Air Cylinder MAC16X125SCA
$34.39
Regular price
$41.89
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MAC16X125SCA
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
MAC Stainless Steel Miniature Cylinder
1. Manufactured in compliance with AirTAC corporate standards;
2. Features custom bidirectional sealing profile with compact dimensions and integrated oil reservoir design for enhanced piston lubrication;
3. Equipped with fixed cushioning pads on both end caps to mitigate directional reversal impact;
4. Multiple rear cover configurations ensure versatile mounting flexibility;
5. Stainless steel barrel and end caps assembled through combined riveting and encapsulation process for robust connection;
6. Precision-engineered from high-grade stainless steel tubing offering exceptional corrosion resistance and structural integrity;
7. Comprehensive selection of cylinder specifications and mounting accessories available for customized applications;
8. Full-range magnetic version standard across series.
Category: Stainless Steel Miniature Cylinders | Brand: AirTAC | Series: MAC
Installation note:
Maximum permissible misalignment: ±2° angular/±0.5mm lateral.
For vertical mounting, use tandem cylinders or external guides when handling >5kg payloads.
Break-in period: 50-100 cycles at 0.3MPa before full-load operation.
1. Manufactured in compliance with AirTAC corporate standards;
2. Features custom bidirectional sealing profile with compact dimensions and integrated oil reservoir design for enhanced piston lubrication;
3. Equipped with fixed cushioning pads on both end caps to mitigate directional reversal impact;
4. Multiple rear cover configurations ensure versatile mounting flexibility;
5. Stainless steel barrel and end caps assembled through combined riveting and encapsulation process for robust connection;
6. Precision-engineered from high-grade stainless steel tubing offering exceptional corrosion resistance and structural integrity;
7. Comprehensive selection of cylinder specifications and mounting accessories available for customized applications;
8. Full-range magnetic version standard across series.
Category: Stainless Steel Miniature Cylinders | Brand: AirTAC | Series: MAC
AirTAC MAC16X125SCA Stainless Steel Mini Cylinder Specifications
- Model: MAC16X125SCA
- Type: Single-acting spring return (push type)
- Bore size: Ø16mm
- Stroke: 125mm (±0.5mm tolerance)
- Material: SUS304 stainless steel body + aluminum alloy end caps
- Operating pressure: 0.05–0.9 MPa
- Temperature range: -20℃ to 150℃
- Cushioning: Adjustable rubber buffer
- Port size: M5x0.8 (standard) with NPT1/8 adaptor optional
- Rod thread: M6x1.0 external thread
- Weight: 0.78kg (complete assembly)
- Dimensions:
- Length: 196mm (fully retracted)
- Width: 32mm (body diameter)
- Height: 42mm (including mounting brackets)
- Lubrication: Pre-lubricated (maintenance-free for 2,000km operation)
- Protection rating: IP67 (dust/water resistant)
Ultra-compact corrosion-resistant cylinder with enhanced side load capacity (up to 15N lateral force). Features anti-rotation guide mechanism and scratch-resistant chromed piston rod (HCP treatment). Compatible with ISO 6432 mounting standards. Requires 5μm filtered air with 1-10mg/m³ oil mist (ISO 8573-1 class 4).
Typical Applications:
- Pharmaceutical tablet pressing machines
- Semiconductor wafer handling robots
- Food packaging line actuators
- Marine equipment controls
- Cleanroom automation systems
Installation note:
Maximum permissible misalignment: ±2° angular/±0.5mm lateral.
For vertical mounting, use tandem cylinders or external guides when handling >5kg payloads.
Break-in period: 50-100 cycles at 0.3MPa before full-load operation.
| Property | Property Value |
|---|---|
| sku | MAC16X125SCA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Stroke | 125mm |
