Airtac MAC Stainless Steel Mini Air Cylinder MAC16X125SCM
$34.39
Regular price
$41.89
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MAC16X125SCM
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
MAC Stainless Steel Miniature Cylinder
1. Manufactured in compliance with AirTAC corporate standards;
2. Features custom bidirectional sealing profile with compact dimensions and integrated oil reservoir design for enhanced piston lubrication;
3. Equipped with fixed cushioning pads on both end caps to mitigate directional reversal impact;
4. Multiple rear cover configurations ensure versatile mounting flexibility;
5. Stainless steel barrel and end caps assembled through combined riveting and encapsulation process for robust connection;
6. Precision-engineered from high-grade stainless steel tubing offering exceptional corrosion resistance and structural integrity;
7. Comprehensive selection of cylinder specifications and mounting accessories available for customized applications;
8. Full-range magnetic version standard across series.
Category: Stainless Steel Miniature Cylinders | Brand: AirTAC | Series: MAC
Installation note:
Maintain 0.5mm alignment tolerance during mounting. For vertical installations exceeding 45° angle,
use guided mounting brackets. Lubricate every 500km stroke distance in high-cycle applications.
Critical notice:
Avoid using chlorinated lubricants with stainless steel components.
Maximum side load capacity: 15N (axial), 8N (radial).
Requires 5μm filtered air for oil-free operation.
1. Manufactured in compliance with AirTAC corporate standards;
2. Features custom bidirectional sealing profile with compact dimensions and integrated oil reservoir design for enhanced piston lubrication;
3. Equipped with fixed cushioning pads on both end caps to mitigate directional reversal impact;
4. Multiple rear cover configurations ensure versatile mounting flexibility;
5. Stainless steel barrel and end caps assembled through combined riveting and encapsulation process for robust connection;
6. Precision-engineered from high-grade stainless steel tubing offering exceptional corrosion resistance and structural integrity;
7. Comprehensive selection of cylinder specifications and mounting accessories available for customized applications;
8. Full-range magnetic version standard across series.
Category: Stainless Steel Miniature Cylinders | Brand: AirTAC | Series: MAC
AirTAC MAC16X125SCM Stainless Steel Mini Cylinder Specifications
- Model: MAC16X125SCM
- Series: MAC (Stainless Steel Miniature Series)
- Bore size: 16mm
- Stroke: 125mm
- Material: Stainless steel cylinder tube & piston rod
- Seal material: NBR/FKM (optional fluorocarbon rubber)
- Operating pressure: 0.1–0.9 MPa
- Operating temperature: -20℃ to 80℃ (NBR) / -10℃ to 150℃ (FKM)
- Cushion type: Adjustable pneumatic cushion
- Mounting style: Basic type (Standard) / MF1 front flange (optional)
- Port size: M5x0.8 (G1/8 adapter available)
- Protection rating: IP65
- Weight: 0.45kg (bare cylinder)
- Dimensions: 190mm(L) × 40mm(W) × 40mm(H)
- Piston speed: 50–800 mm/s
- Lubrication: Pre-lubricated (Optional oil-free operation)
Premium corrosion-resistant cylinder with ultra-compact profile (40% smaller than standard cylinders). Features stainless steel construction for chemical resistance and hygienic applications. Integrated shock absorption reduces end-impact noise by 15dB. Optional auto switch slots for magnetic sensor compatibility.
Typical Applications:
- Pharmaceutical packaging machinery
- Food processing automation lines
- Semiconductor wafer handling robots
- Marine equipment actuators
- Cleanroom medical devices
Installation note:
Maintain 0.5mm alignment tolerance during mounting. For vertical installations exceeding 45° angle,
use guided mounting brackets. Lubricate every 500km stroke distance in high-cycle applications.
Critical notice:
Avoid using chlorinated lubricants with stainless steel components.
Maximum side load capacity: 15N (axial), 8N (radial).
Requires 5μm filtered air for oil-free operation.
| Property | Property Value |
|---|---|
| sku | MAC16X125SCM |
| Rear Cover Type | Round Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Stroke | 125mm |
