Airtac MAC Stainless Steel Mini Air Cylinder MAC16X125SU
1. Manufactured in compliance with AirTAC corporate standards;
2. Features custom bidirectional sealing profile with compact dimensions and integrated oil reservoir design for enhanced piston lubrication;
3. Equipped with fixed cushioning pads on both end caps to mitigate directional reversal impact;
4. Multiple rear cover configurations ensure versatile mounting flexibility;
5. Stainless steel barrel and end caps assembled through combined riveting and encapsulation process for robust connection;
6. Precision-engineered from high-grade stainless steel tubing offering exceptional corrosion resistance and structural integrity;
7. Comprehensive selection of cylinder specifications and mounting accessories available for customized applications;
8. Full-range magnetic version standard across series.
Category: Stainless Steel Miniature Cylinders | Brand: AirTAC | Series: MAC
AirTAC MAC16X125SU Stainless Steel Mini Cylinder Technical Details
- Model Series: MAC stainless steel compact cylinder
- Bore Size: 16mm (0.63")
- Stroke: 125mm (4.92")
- Operating Pressure: 0.05-1.0 MPa (7-145 PSI)
- Ambient Temperature: -20℃ to 80℃ (-4°F to 176°F)
- Cushioning: Adjustable rubber bumper (both ends)
- Port Thread: M5x0.8 (standard), G1/8 optional
- Piston Material: SUS304 stainless steel
- Rod Material: SUS304 stainless steel with hard chrome plating
- Seal Type: Fluorocarbon rubber (FKM) for high temp resistance
- Max Speed: 500-800 mm/s (with cushioning)
- Weight: 0.92 kg (2.03 lbs)
- Dimensions (L×W×H):
- Retracted: 160mm (6.30")
- Extended: 285mm (11.22")
- Body Width: 34mm (1.34")
- Mounting Base: 20mm × 20mm (0.79" × 0.79")
Corrosion-resistant mini cylinder engineered for precision linear motion in harsh environments. Features full stainless steel construction with IP67 protection rating, making it ideal for washdown applications. The compact design achieves 40% space savings compared to standard cylinders while maintaining 20% higher lateral load capacity through reinforced guide structure.
- Pharmaceutical cleanroom automation
- Food packaging machinery (FDA-compliant)
- Semiconductor wafer handling robots
- Marine equipment actuators
- Chemical processing valve controls
- High-cycle CNC tool changers (500k+ cycles)
Maintenance Protocol:
Lubricate with ISO VG32 hydraulic oil monthly in high-cycling applications.
Avoid side load exceeding 15N. Use stainless steel air lines to prevent
galvanic corrosion. Alignment tolerance: ±0.5mm perpendicularity.
| Property | Property Value |
|---|---|
| sku | MAC16X125SU |
| Rear Cover Type | Flat Tail Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Stroke | 125mm |
