Airtac MAC Stainless Steel Mini Air Cylinder MAC16X150SCA
1. Manufactured in compliance with AirTAC corporate standards;
2. Features custom bidirectional sealing profile with compact dimensions and integrated oil reservoir design for enhanced piston lubrication;
3. Equipped with fixed cushioning pads on both end caps to mitigate directional reversal impact;
4. Multiple rear cover configurations ensure versatile mounting flexibility;
5. Stainless steel barrel and end caps assembled through combined riveting and encapsulation process for robust connection;
6. Precision-engineered from high-grade stainless steel tubing offering exceptional corrosion resistance and structural integrity;
7. Comprehensive selection of cylinder specifications and mounting accessories available for customized applications;
8. Full-range magnetic version standard across series.
Category: Stainless Steel Miniature Cylinders | Brand: AirTAC | Series: MAC
AirTAC MAC16X150SCA Stainless Steel Mini Cylinder Technical Details
- Model: MAC16X150SCA
- Bore size: 16mm
- Stroke: 150mm
- Material: SUS304 stainless steel (body), aluminum alloy (end caps)
- Operating pressure: 0.15–0.8 MPa
- Operating temperature: -20℃ to 150℃
- Cushioning: Adjustable rubber buffer (both ends)
- Port size: M5x0.8 (dual ports)
- Rod thread: M6x1.0
- Piston speed: 50–800 mm/s
- Mounting type: Basic (no built-in mounts)
- Weight: 480g ±2%
- Dimensions:
- Extended length: 246mm
- Retracted length: 96mm
- Body diameter: 28mm
- Rod diameter: 6mm
- ISO standard: 6432 (compact cylinder specifications)
Corrosion-resistant mini cylinder with full stainless steel construction for harsh environments. Features precision-ground rod and double lip seals (NBR/FKM optional) for minimal friction and zero leakage. Requires 5μm filtered air with ISO 8573-1:2010 Class 3.4.2 quality. Lubrication: ISO VG32 turbine oil recommended.
- Semiconductor wafer handling robots
- Pharmaceutical tablet pressing machines
- Food packaging line actuators
- Marine equipment controls
- Cleanroom automation systems (ISO Class 5-8)
Installation guidelines:
Maximum side load ≤15N. For vertical mounting, use guide brackets if lateral forces exceed 5N.
Allow 0.5mm thermal expansion gap per 100mm stroke at >80℃ environments.
| Property | Property Value |
|---|---|
| sku | MAC16X150SCA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Stroke | 150mm |
