Airtac MAC Stainless Steel Mini Air Cylinder MAC16X150SCM
1. Manufactured in compliance with AirTAC corporate standards;
2. Features custom bidirectional sealing profile with compact dimensions and integrated oil reservoir design for enhanced piston lubrication;
3. Equipped with fixed cushioning pads on both end caps to mitigate directional reversal impact;
4. Multiple rear cover configurations ensure versatile mounting flexibility;
5. Stainless steel barrel and end caps assembled through combined riveting and encapsulation process for robust connection;
6. Precision-engineered from high-grade stainless steel tubing offering exceptional corrosion resistance and structural integrity;
7. Comprehensive selection of cylinder specifications and mounting accessories available for customized applications;
8. Full-range magnetic version standard across series.
Category: Stainless Steel Miniature Cylinders | Brand: AirTAC | Series: MAC
AirTAC MAC16X150SCM Stainless Steel Mini Cylinder Specifications
- Model: MAC16X150SCM
- Bore size: 16mm
- Stroke: 150mm
- Material: SUS304 stainless steel (rod/piston/tube)
- Operating pressure: 0.1–1.0 MPa
- Operating temperature: -20℃ to 80℃
- Cushion type: Rubber buffer (adjustable)
- Mounting style: Front flange (MF1), optional rear pivot/rod clevis
- Port size: M5x0.8 (standard), G1/8 available on request
- Rod end: External thread M6x1.0
- Weight: 420g ±5% (with standard fittings)
- Dimensions: 200mm(L) × 30mm(W) × 50mm(H)
- Piston seal: NBR rubber (FDA compliant option: FKM)
- Rod wiper: Polyurethane
- Repeat accuracy: ±0.2mm
- Max speed: 500mm/s
Corrosion-resistant mini cylinder with full stainless steel construction, designed for cleanroom environments and washdown applications. Features anti-rotation rod guidance and dual cushioning system for precise linear motion control. Requires ISO 8573-1:2010 Class 3-4-3 compressed air.
- Pharmaceutical packaging machinery
- Food processing automation lines
- Semiconductor wafer handling systems
- Marine equipment actuators
- Laboratory liquid dispensing robots
Installation note:
Lubricate with ISO VG32 hydraulic oil before initial use.
Avoid side load exceeding 3N·m. For vertical mounting,
use counterbalance valves when handling suspended loads.
| Property | Property Value |
|---|---|
| sku | MAC16X150SCM |
| Rear Cover Type | Round Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Stroke | 150mm |
