Airtac MAC Stainless Steel Mini Air Cylinder MAC16X15SCA
$30.00
Regular price
$37.50
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MAC16X15SCA
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
MAC Stainless Steel Miniature Cylinder
1. Manufactured in compliance with AirTAC corporate standards;
2. Features custom bidirectional sealing profile with compact dimensions and integrated oil reservoir design for enhanced piston lubrication;
3. Equipped with fixed cushioning pads on both end caps to mitigate directional reversal impact;
4. Multiple rear cover configurations ensure versatile mounting flexibility;
5. Stainless steel barrel and end caps assembled through combined riveting and encapsulation process for robust connection;
6. Precision-engineered from high-grade stainless steel tubing offering exceptional corrosion resistance and structural integrity;
7. Comprehensive selection of cylinder specifications and mounting accessories available for customized applications;
8. Full-range magnetic version standard across series.
Category: Stainless Steel Miniature Cylinders | Brand: AirTAC | Series: MAC
Installation note:
Use PTFE-based lubricant for maintenance. Avoid side load exceeding 2N·m.
For vertical mounting, reduce payload capacity by 30%. Always install
speed controller when operating above 300mm/s.
Critical specification:
Requires 0.1-0.5μm filtration for optimal seal life. Not compatible with
chlorinated or oxygen-rich atmospheres (>23% O₂).
1. Manufactured in compliance with AirTAC corporate standards;
2. Features custom bidirectional sealing profile with compact dimensions and integrated oil reservoir design for enhanced piston lubrication;
3. Equipped with fixed cushioning pads on both end caps to mitigate directional reversal impact;
4. Multiple rear cover configurations ensure versatile mounting flexibility;
5. Stainless steel barrel and end caps assembled through combined riveting and encapsulation process for robust connection;
6. Precision-engineered from high-grade stainless steel tubing offering exceptional corrosion resistance and structural integrity;
7. Comprehensive selection of cylinder specifications and mounting accessories available for customized applications;
8. Full-range magnetic version standard across series.
Category: Stainless Steel Miniature Cylinders | Brand: AirTAC | Series: MAC
AirTAC MAC16X15SCA Stainless Steel Mini Cylinder Specifications
- Model: MAC16X15SCA
- Bore size: 16mm
- Stroke: 15mm (±1mm tolerance)
- Operating pressure: 0.05–1.0 MPa
- Operating medium: Dry air (ISO8573-1:2010 Class 3)
- Ambient temperature: -20℃ to 150℃
- Cylinder material: SUS304 stainless steel
- Piston rod material: SUS303 stainless steel
- Cushioning: Adjustable rubber buffer
- Mounting type: Basic front flange (MF12)
- Port size: M5x0.8 (Rc1/8 adapter optional)
- Seal material: Fluororubber (FKM)
- Protection rating: IP67
- Weight: 0.27kg
- Dimensions: 58mm(L) × 42mm(W) × 42mm(H) (at mid-stroke)
- Max speed: 500mm/s
- Lubrication: Pre-lubricated (Do not mix with petroleum-based oils)
Ultra-compact stainless steel cylinder engineered for corrosive environments and high-temperature applications. Features non-magnetic construction with mirror-finished rod surface (Ra≤0.2μm) for particle-sensitive environments. Integrated auto-switch groove (5mm width) enables sensor mounting without brackets.
Typical Applications:
- Cleanroom automation in semiconductor manufacturing
- Food processing machinery (NSF compliant)
- Pharmaceutical tablet pressing mechanisms
- Marine equipment actuators
- Sterilization chamber door locks
Installation note:
Use PTFE-based lubricant for maintenance. Avoid side load exceeding 2N·m.
For vertical mounting, reduce payload capacity by 30%. Always install
speed controller when operating above 300mm/s.
Critical specification:
Requires 0.1-0.5μm filtration for optimal seal life. Not compatible with
chlorinated or oxygen-rich atmospheres (>23% O₂).
| Property | Property Value |
|---|---|
| sku | MAC16X15SCA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Stroke | <15mm> |
