Airtac MAC Stainless Steel Mini Air Cylinder MAC16X160SCA
1. Manufactured in compliance with AirTAC corporate standards;
2. Features custom bidirectional sealing profile with compact dimensions and integrated oil reservoir design for enhanced piston lubrication;
3. Equipped with fixed cushioning pads on both end caps to mitigate directional reversal impact;
4. Multiple rear cover configurations ensure versatile mounting flexibility;
5. Stainless steel barrel and end caps assembled through combined riveting and encapsulation process for robust connection;
6. Precision-engineered from high-grade stainless steel tubing offering exceptional corrosion resistance and structural integrity;
7. Comprehensive selection of cylinder specifications and mounting accessories available for customized applications;
8. Full-range magnetic version standard across series.
Category: Stainless Steel Miniature Cylinders | Brand: AirTAC | Series: MAC
AirTAC MAC16X160SCA Stainless Steel Mini Cylinder Specifications
- Model: MAC16X160SCA
- Type: Single-acting spring return (push type)
- Bore size: 16mm
- Stroke: 160mm
- Material: Stainless steel (SUS304 barrel, CR rod)
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃ (NBR seals)
- Cushioning: Adjustable buffer
- Mounting style: Basic type (MF1) / Front flange (MF3 optional)
- Port size: M5x0.8 (1/8" NPT adaptor available)
- Weight: ~380g (without accessories)
- Dimensions: 218mm(L) × 34mm(W) × 34mm(H) (full extension)
- Rod thread: M6x1.0 external thread
- Max speed: 500mm/s
- Protection rating: IP67
Corrosion-resistant mini cylinder optimized for precision linear motion in compact spaces. Features hardened piston rod (HRC 45-50) and low-friction seals for smooth operation. Includes magnetic piston for position sensing compatibility. Requires 40μm filtered air with ISO VG32 lubricant (optional oil-free operation).
- Medical device actuation systems
- Semiconductor wafer handling robots
- Food packaging machinery (NSF compliant)
- Precision valve operators
- Cleanroom automation equipment
Installation tip:
Maintain 0.5-1mm clearance between rod end and load during alignment.
For vertical mounting, use spring-extend orientation to prevent seal wear.
| Property | Property Value |
|---|---|
| sku | MAC16X160SCA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Stroke | 160mm |
