Airtac MAC Stainless Steel Mini Air Cylinder MAC16X160SCM
$36.98
Regular price
$44.48
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MAC16X160SCM
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
MAC Stainless Steel Miniature Cylinder
1. Manufactured in compliance with AirTAC corporate standards;
2. Features custom bidirectional sealing profile with compact dimensions and integrated oil reservoir design for enhanced piston lubrication;
3. Equipped with fixed cushioning pads on both end caps to mitigate directional reversal impact;
4. Multiple rear cover configurations ensure versatile mounting flexibility;
5. Stainless steel barrel and end caps assembled through combined riveting and encapsulation process for robust connection;
6. Precision-engineered from high-grade stainless steel tubing offering exceptional corrosion resistance and structural integrity;
7. Comprehensive selection of cylinder specifications and mounting accessories available for customized applications;
8. Full-range magnetic version standard across series.
Category: Stainless Steel Miniature Cylinders | Brand: AirTAC | Series: MAC
Installation note:
Apply anti-seize compound on stainless steel threads. For full stroke operation,
maintain 0.5-1.0 MPa pressure. Lubricate every 3 months in continuous duty cycles.
1. Manufactured in compliance with AirTAC corporate standards;
2. Features custom bidirectional sealing profile with compact dimensions and integrated oil reservoir design for enhanced piston lubrication;
3. Equipped with fixed cushioning pads on both end caps to mitigate directional reversal impact;
4. Multiple rear cover configurations ensure versatile mounting flexibility;
5. Stainless steel barrel and end caps assembled through combined riveting and encapsulation process for robust connection;
6. Precision-engineered from high-grade stainless steel tubing offering exceptional corrosion resistance and structural integrity;
7. Comprehensive selection of cylinder specifications and mounting accessories available for customized applications;
8. Full-range magnetic version standard across series.
Category: Stainless Steel Miniature Cylinders | Brand: AirTAC | Series: MAC
AirTAC MAC16X160SCM Stainless Steel Mini Cylinder Specifications
- Model: MAC16X160SCM
- Bore size: 16mm
- Stroke: 160mm
- Material: Stainless steel (SUS304 barrel, SUS303 piston rod)
- Operating pressure: 0.1–1.0 MPa
- Operating temperature: -20℃ to 150℃
- Cushion type: Adjustable rubber buffer (both ends)
- Port size: M5 × 0.8 (Rc1/8 adapter included)
- Piston rod thread: M6 × 1.0 (external)
- Weight: 480g ±5%
- Dimensions: 200mm(L) × 34mm(W) × 34mm(H)
- Seal material: Fluororubber (FKM)
- Max speed: 500mm/s
- ISO standard: 6432 compliant
- Mounting style: Front/rear threaded (M6×1.0)
- Sensor compatibility: Magnetic reed switch (2-wire)
Corrosion-resistant mini cylinder with full stainless steel construction, designed for precision linear motion in harsh environments. Features non-rotating piston rod (keyway-guided) and IP67 protection rating. Requires 5μm filtered air and ISO VG32 hydraulic oil lubrication (optional).
Typical Applications:
- Food processing equipment (washdown environments)
- Pharmaceutical blister packaging machines
- Semiconductor wafer handling systems
- Marine automation controls
- Laboratory sample positioning stages
Installation note:
Apply anti-seize compound on stainless steel threads. For full stroke operation,
maintain 0.5-1.0 MPa pressure. Lubricate every 3 months in continuous duty cycles.
| Property | Property Value |
|---|---|
| sku | MAC16X160SCM |
| Rear Cover Type | Round Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Stroke | 160mm |
